CMP PRODUCTS电缆接头技术数据
CMP PRODUCTS电缆接头技术数据
防爆
类型：CMP-20S16-A2FFC
制造商零件编号：20S16A2FFC1RA5C030
螺纹尺寸：M20x1.5
螺纹长度：15毫米
材质：镀镍黄铜
夹紧范围：3.2 ... 8.1 mm
扳手尺寸：24.00
铠装类型：非铠装电缆类型
防护编织电缆
内夹克：3.2 ... 8.1毫米
应用区域（区域）：1，2，20，21
防护等级（IP）：IP66
气体爆炸防护：II 2 G Ex db IIC Gb
II 2 G Ex eb IIC Gb
防尘防爆：II 1 D Ex ta IIIC Da
最低环境温度 ：-60°C
最高环境温度 ：+130°C
电缆接头：螺纹转换和附件
CMP设计了一系列高质量的螺纹转换适配器，异径管和相关附件，用于各种电缆连接情况。该系列特别适用于使用大量不同类型和尺寸的电缆的大型建筑项目。
当电缆密封套适合电缆但连接螺纹不同时，最好的解决方案可能是使用螺纹转换适配器，尤其是在时间表很紧迫且时间至关重要的情况下。
范围包括接头，塞子塞，通气/排水塞和绝缘适配器。这些产品中的每一种都有不同螺纹形式和尺寸的组合，包括公制，PG，NPT，BSP等。
此系列的CMP工业，海洋和爆炸性大气产品提供了一系列国际认可的机构，包括ATEX，IECEx，cCSAus，UL等。
CMP针对工业、海事应用和易爆环境设计并生产电缆密封接头、电缆夹及其相关产品。
电缆密封接头适用范围广泛，符合不同的国际安装规范（从IEC到NEC），还可以应要求提供多种不同的认证。我们的产品使用各种不同的材质，确保能够在有限的前置时间里为特定环境提供合适的电缆密封接头。
我们富有创新性的电缆夹既有标准产品也有定制产品，还可使用不同材质，确保为客户提供不同电缆夹，应对各种可能发生的情况。该系列的所有产品都根据IEC 61914:2009进行设计和认证，确保安全第一的原则。
