专业进口德国Danly弹簧

专业进口德国Danly弹簧

Danly IEM是北美工业模具制造用品和组件的制造商。90多年来Danly IEM一直提供高质量的产品和服务、创新开发和定制产品。

Danly IEM产品系列包括广泛的导柱、衬套、模具弹簧、冲头、气压机、耐磨板和凸轮，以及其他模具制造商的用品。我们还提供特殊的冲头和定制产品，以满足客户的要求。

Danly IEM的目标之一是行业提供产品，帮助客户找到改善运营的解决方案。攻丝工具的开发为提高客户效率提供了机会。这些工具允许客户在冲压操作中攻丝产品，从而消除攻丝产品的二次操作。

高伟小组
QQ：2853369888

手机：17710704891
电话：010-64714988-215
传真：010-64714988-668
邮件：tk5@handelsen.cn

高伟小组邮箱：tk5@handelsen.cn电话：010-64714988-215

为了保持我们的地位和声誉，我们大力投资开发最先进的制造设备。

Danly IEM是全球零件成型行业值得信赖的解决方案和创新的名称。

Danly弹簧产品目录

DieMax XL Springs: Light Load (Green)

Part No.	Description	Wire Type	A - Hole Diameter	C - Free Length	Spring Constant
9-0604-11	SPRG.0.375X 1.00 GREEN	Rectangular	3/8(in) 10(mm)	1.00(in) 25(mm)	6.30(lbs per 1/10in) 11.0(N/mm)
9-0604-119	ROUND SPRING 0.375X1.0 GREEN	Round	3/8(in)	1.00(in)	2.52(lbs per 1/10in)
9-0605-11	SPRG.0.375X 1.25-GREEN	Rectangular	3/8(in) 10(mm)	1.25(in) 32(mm)	5.00(lbs per 1/10in) 8.8(N/mm)
9-0605-119	ROUND SPRG.0.375X1.25GREEN	Round	3/8(in)	1.25(in)	1.96(lbs per 1/10in)
9-0606-11	SPRG.0.375X 1.50-GREEN	Rectangular	3/8(in) 10(mm)	1.50(in) 38(mm)	4.22(lbs per 1/10in) 7.4(N/mm)
9-0606-119	ROUND SPRG.0.375X1.50GREEN	Round	3/8(in)	1.50(in)	1.59(lbs per 1/10in)
9-0607-11	SPRG.0.375X 1.75-GREEN	Rectangular	3/8(in) 10(mm)	1.75(in) 44(mm)	3.59(lbs per 1/10in) 6.3(N/mm)
9-0607-119	ROUND SPRG.0.375X1.75GREEN	Round	3/8(in)	1.75(in)	1.35(lbs per 1/10in)
9-0608-11	SPRG.0.375X 2.00-GREEN	Rectangular	3/8(in) 10(mm)	2.00(in) 51(mm)	3.06(lbs per 1/10in) 5.4(N/mm)
9-0608-119	ROUND SPRG.0.375X2.00GREEN	Round	3/8(in)	2.00(in)	1.19(lbs per 1/10in)
9-0610-11	SPRG.0.375X 2.50-GREEN	Rectangular	3/8(in) 10(mm)	2.50(in) 64(mm)	2.56(lbs per 1/10in) 4.5(N/mm)
9-0610-119	ROUND SPRG.0.375X2.50GREEN	Round	3/8(in)	2.50(in)	0.93(lbs per 1/10in)
9-0612-11	SPRG.0.375X 3.00-GREEN	Rectangular	3/8(in) 10(mm)	3.00(in) 76(mm)	2.13(lbs per 1/10in) 3.7(N/mm)
9-0612-119	ROUND SPRG.0.375X3.00GREEN	Round	3/8(in)	3.00(in)	0.76(lbs per 1/10in)
9-0648-11	SPRG.0.375X12.0 GREEN	Rectangular	3/8(in) 10(mm)	12.00(in) 305(mm)	0.49(lbs per 1/10in) 0.9(N/mm)
9-0648-119	ROUND SPRG.0.375X12.0GREEN	Round	3/8(in)	12.00(in)	0.18(lbs per 1/10in)
9-0804-11	SPRG.0.500X 1.00-GREEN	Rectangular	1/2(in) 12.5(mm)	1.00(in) 25(mm)	10.90(lbs per 1/10in) 19.0(N/mm)
9-0804-119	ROUND SPRG.0.500X1.00GREEN	Round	1/2(in)	1.00(in)	4.88(lbs per 1/10in)
9-0805-11	SPRG.0.500X 1.25-GREEN	Rectangular	1/2(in) 12.5(mm)	1.25(in) 32(mm)	9.40(lbs per 1/10in) 16.5(N/mm)
9-0805-119	ROUND SPRG.0.500X1.25GREEN	Round	1/2(in)	1.25(in)	3.71(lbs per 1/10in)
9-0806-11	SPRG.0.500X 1.50-GREEN	Rectangular	1/2(in) 12.5(mm)	1.50(in) 38(mm)	7.80(lbs per 1/10in) 13.6(N/mm)
9-0806-119	ROUND SPRG.0.500X1.50-GREEN	Round	1/2(in)	1.50(in)	3.04(lbs per 1/10in)
9-0807-11	SPRG.0.500X 1.75-GREEN	Rectangular	1/2(in) 12.5(mm)	1.75(in) 44(mm)	6.60(lbs per 1/10in) 11.6(N/mm)
9-0807-119	ROUND SPRG.0.500X1.75-GREEN	Round	1/2(in)	1.75(in)	2.54(lbs per 1/10in)
9-0808-11	SPRG.0.500X 2.00-GREEN	Rectangular	1/2(in) 12.5(mm)	2.00(in) 51(mm)	5.80(lbs per 1/10in) 10.2(N/mm)
9-0808-119	ROUND SPRG.0.500X2.00-GREEN	Round	1/2(in)	2.00(in)	2.17(lbs per 1/10in)
9-0810-11	SPRG.0.500X 2.50-GREEN	Rectangular	1/2(in) 12.5(mm)	2.50(in) 64(mm)	4.67(lbs per 1/10in) 8.2(N/mm)
9-0810-119	ROUND SPRG.0.500X2.50-GREEN	Round	1/2(in)	2.50(in)	1.68(lbs per 1/10in)
9-0812-11	SPRG.0.500X 3.00-GREEN	Rectangular	1/2(in) 12.5(mm)	3.00(in) 76(mm)	3.58(lbs per 1/10in) 6.3(N/mm)
9-0812-119	ROUND SPRG.0.500X3.00-GREEN	Round	1/2(in)	3.00(in)	1.43(lbs per 1/10in)
9-0814-11	SPRG.0.500X 3.50-GREEN	Rectangular	1/2(in) 12.5(mm)	3.50(in) 89(mm)	3.05(lbs per 1/10in) 5.3(N/mm)
9-0814-119	ROUND SPRG.0.500X3.50-GREEN	Round	1/2(in)	3.50(in)	1.22(lbs per 1/10in)
9-0848-11	SPRG.0.500x12.0-GREEN	Rectangular	1/2(in) 12.5(mm)	12.00(in) 305(mm)	0.84(lbs per 1/10in) 1.5(N/mm)
9-0848-119	ROUND SPRG.0.500x12.0-GREEN	Round	1/2(in)	12.00(in)	0.34(lbs per 1/10in)
9-1004-11	SPRG.0.625X 1.00-GREEN	Rectangular	5/8(in) 16(mm)	1.00(in) 25(mm)	18.00(lbs per 1/10in) 31.6(N/mm)
9-1004-119	ROUND SPRG.0.625X1.00-GREEN	Round	5/8(in)	1.00(in)	10.20(lbs per 1/10in)
9-1005-11	SPRG.0.625X 1.25-GREEN	Rectangular	5/8(in) 16(mm)	1.25(in) 32(mm)	13.40(lbs per 1/10in) 23.5(N/mm)
9-1005-119	ROUND SPRG.0.625X1.25-GREEN	Round	5/8(in)	1.25(in)	7.70(lbs per 1/10in)
9-1006-11	SPRG.0.625X 1.50-GREEN	Rectangular	5/8(in) 16(mm)	1.50(in) 38(mm)	12.00(lbs per 1/10in) 21.0(N/mm)
9-1006-119	ROUND SPRG.0.625X1.50-GREEN	Round	5/8(in)	1.50(in)	6.00(lbs per 1/10in)
9-1007-11	SPRG.0.625X 1.75-GREEN	Rectangular	5/8(in) 16(mm)	1.75(in) 44(mm)	10.00(lbs per 1/10in) 17.5(N/mm)
9-1007-119	ROUND SPRG.0.625X1.75-GREEN	Round	5/8(in)	1.75(in)	5.00(lbs per 1/10in)
9-1008-11	SPRG.0.625X 2.00-GREEN	Rectangular	5/8(in) 16(mm)	2.00(in) 51(mm)	9.30(lbs per 1/10in) 16.2(N/mm)
9-1008-119	ROUND SPRG.0.625X2.00-GREEN	Round	5/8(in)	2.00(in)	4.33(lbs per 1/10in)
9-1010-11	SPRG.0.625X 2.50-GREEN	Rectangular	5/8(in) 16(mm)	2.50(in) 64(mm)	7.20(lbs per 1/10in) 12.5(N/mm)
9-1010-119	ROUND SPRG.0.625X2.50-GREEN	Round	5/8(in)	2.50(in)	3.38(lbs per 1/10in)
9-1012-11	SPRG.0.625X 3.00-GREEN	Rectangular	5/8(in) 16(mm)	3.00(in) 76(mm)	5.90(lbs per 1/10in) 10.3(N/mm)
9-1012-119	ROUND SPRG.0.625X3GREEN	Round	5/8(in)	3.00(in)	2.73(lbs per 1/10in)
9-1014-11	SPRG.0.625X 3.50-GREEN	Rectangular	5/8(in) 16(mm)	3.50(in) 89(mm)	5.30(lbs per 1/10in) 9.3(N/mm)
9-1014-119	GRN ROUND SPRG.0.625X3.50-GREEN	Round	5/8(in)	3.50(in)	2.31(lbs per 1/10in)
Part No.	Description	Wire Type	A - Hole Diameter	C - Free Length	Spring Constant
9-1016-11	SPRG.0.625X 4.00-GREEN	Rectangular	5/8(in) 16(mm)	4.00(in) 102(mm)	4.70(lbs per 1/10in) 8.2(N/mm)
9-1016-119	ROUND SPRG.0.625X4GREEN	Round	5/8(in)	4.00(in)	2.01(lbs per 1/10in)
9-1048-11	SPRG.0.625X12.0-GREEN	Rectangular	5/8(in) 16(mm)	12.00(in) 305(mm)	1.50(lbs per 1/10in) 2.6(N/mm)
9-1048-119	ROUND SPRG.0.625X1GREEN	Round	5/8(in)	12.00(in)	0.64(lbs per 1/10in)
9-1204-11	SPRG.0.750X 1.00-GREEN	Rectangular	3/4(in) 20(mm)	1.00(in) 25(mm)	32.00(lbs per 1/10in) 56.0(N/mm)
9-1205-11	SPRG-0.750X 1.25-GREEN	Rectangular	3/4(in) 20(mm)	1.25(in) 32(mm)	24.40(lbs per 1/10in) 42.7(N/mm)
9-1206-11	SPRG.0.750X 1.50-GREEN	Rectangular	3/4(in) 20(mm)	1.50(in) 38(mm)	19.30(lbs per 1/10in) 33.8(N/mm)
9-1207-11	SPRG.0.750X 1.75-GREEN	Rectangular	3/4(in) 20(mm)	1.75(in) 44(mm)	16.20(lbs per 1/10in) 28.4(N/mm)
9-1208-11	SPRG.0.750X 2.00-GREEN	Rectangular	3/4(in) 20(mm)	2.00(in) 51(mm)	14.20(lbs per 1/10in) 24.8(N/mm)
9-1210-11	SPRG.0.750X 2.50-GREEN	Rectangular	3/4(in) 20(mm)	2.50(in) 64(mm)	11.00(lbs per 1/10in) 19.2(N/mm)
9-1212-11	SPRG.0.750X 3.00-GREEN	Rectangular	3/4(in) 20(mm)	3.00(in) 76(mm)	9.20(lbs per 1/10in) 16.1(N/mm)
9-1214-11	SPRG.0.750X 3.50-GREEN	Rectangular	3/4(in) 20(mm)	3.50(in) 89(mm)	7.70(lbs per 1/10in) 13.4(N/mm)
9-1216-11	SPRG.0.750X 4.00-GREEN	Rectangular	3/4(in) 20(mm)	4.00(in) 102(mm)	6.80(lbs per 1/10in) 11.8(N/mm)
9-1218-11	SPRG.0.750X 4.50-GREEN	Rectangular	3/4(in) 20(mm)	4.50(in) 115(mm)	6.00(lbs per 1/10in) 10.5(N/mm)
9-1220-11	SPRG.0.750X 5.00-GREEN	Rectangular	3/4(in) 20(mm)	5.00(in) 127(mm)	5.30(lbs per 1/10in) 9.3(N/mm)
9-1222-11	SPRG.0.750X 5.50-GREEN	Rectangular	3/4(in) 20(mm)	5.50(in) 139(mm)	4.85(lbs per 1/10in) 8.5(N/mm)
9-1224-11	SPRG.0.750X 6.00-GREEN	Rectangular	3/4(in) 20(mm)	6.00(in) 152(mm)	4.50(lbs per 1/10in) 7.9(N/mm)
9-1248-11	SPRG.0.750x12.0-GREEN	Rectangular	3/4(in) 20(mm)	12.00(in) 305(mm)	2.16(lbs per 1/10in) 3.8(N/mm)
9-1604-11	SPRG.1.000X 1.00-GREEN	Rectangular	1(in) 25(mm)	1.00(in) 25(mm)	61.20(lbs per 1/10in) 107.0(N/mm)
9-1605-11	SPRG.1.000X 1.25-GREEN	Rectangular	1(in) 25(mm)	1.25(in) 32(mm)	46.20(lbs per 1/10in) 80.8(N/mm)
9-1606-11	SPRG.1.000X 1.50-GREEN	Rectangular	1(in) 25(mm)	1.50(in) 38(mm)	37.00(lbs per 1/10in) 64.8(N/mm)
9-1607-11	SPRG.1.000X 1.75-GREEN	Rectangular	1(in) 25(mm)	1.75(in) 44(mm)	30.60(lbs per 1/10in) 53.6(N/mm)
9-1608-11	SPRG.1.000X 2.00-GREEN	Rectangular	1(in) 25(mm)	2.00(in) 51(mm)	26.50(lbs per 1/10in) 46.5(N/mm)
9-1610-11	SPRG.1.000X 2.50-GREEN	Rectangular	1(in) 25(mm)	2.50(in) 64(mm)	20.40(lbs per 1/10in) 35.7(N/mm)
9-1612-11	SPRG.1.000X 3.00-GREEN	Rectangular	1(in) 25(mm)	3.00(in) 76(mm)	16.80(lbs per 1/10in) 29.3(N/mm)
9-1614-11	SPRG.1.000X 3.50-GREEN	Rectangular	1(in) 25(mm)	3.50(in) 89(mm)	14.10(lbs per 1/10in) 24.7(N/mm)
9-1616-11	SPRG.1.000X 4.00-GREEN	Rectangular	1(in) 25(mm)	4.00(in) 102(mm)	12.10(lbs per 1/10in) 21.3(N/mm)
9-1618-11	SPRG.1.000X 4.50-GREEN	Rectangular	1(in) 25(mm)	4.50(in) 115(mm)	10.70(lbs per 1/10in) 18.7(N/mm)
9-1620-11	SPRG.1.000X 5.00-GREEN	Rectangular	1(in) 25(mm)	5.00(in) 127(mm)	9.60(lbs per 1/10in) 16.8(N/mm)
9-1622-11	SPRG.1.000X 5.50-GREEN	Rectangular	1(in) 25(mm)	5.50(in) 139(mm)	8.70(lbs per 1/10in) 15.3(N/mm)
9-1624-11	SPRG.1.000X 6.00-GREEN	Rectangular	1(in) 25(mm)	6.00(in) 152(mm)	8.00(lbs per 1/10in) 14.1(N/mm)
9-1628-11	SPRG.1.000X 7.00-GREEN	Rectangular	1(in) 25(mm)	7.00(in) 178(mm)	6.90(lbs per 1/10in) 12.1(N/mm)
9-1632-11	SPRG.1.000X 8.00-GREEN	Rectangular	1(in) 25(mm)	8.00(in) 203(mm)	6.00(lbs per 1/10in) 10.6(N/mm)
9-1648-11	SPRG.1.000x12.0-GREEN	Rectangular	1(in) 25(mm)	12.00(in) 305(mm)	4.00(lbs per 1/10in) 7.0(N/mm)
9-2006-11	SPRG.1.250X 1.50-GREEN	Rectangular	1 1/4(in) 32(mm)	1.50(in) 38(mm)	57.90(lbs per 1/10in) 101.0(N/mm)
9-2007-11	SPRG.1.250X 1.75-GREEN	Rectangular	1 1/4(in) 32(mm)	1.75(in) 44(mm)	47.50(lbs per 1/10in) 83.2(N/mm)
9-2008-11	SPRG.1.250X 2.00-GREEN	Rectangular	1 1/4(in) 32(mm)	2.00(in) 51(mm)	40.70(lbs per 1/10in) 71.3(N/mm)
9-2010-11	SPRG.1.250X 2.50-GREEN	Rectangular	1 1/4(in) 32(mm)	2.50(in) 64(mm)	31.40(lbs per 1/10in) 55.0(N/mm)
9-2012-11	SPRG.1.250X 3.00-GREEN	Rectangular	1 1/4(in) 32(mm)	3.00(in) 76(mm)	26.30(lbs per 1/10in) 46.0(N/mm)
9-2014-11	SPRG.1.250X 3.50-GREEN	Rectangular	1 1/4(in) 32(mm)	3.50(in) 89(mm)	22.20(lbs per 1/10in) 38.8(N/mm)
9-2016-11	SPRG.1.250X 4.00-GREEN	Rectangular	1 1/4(in) 32(mm)	4.00(in) 102(mm)	19.20(lbs per 1/10in) 33.6(N/mm)
9-2018-11	SPRG.1.250X 4.50-GREEN	Rectangular	1 1/4(in) 32(mm)	4.50(in) 115(mm)	16.90(lbs per 1/10in) 29.6(N/mm)
9-2020-11	SPRG.1.250X 5.00-GREEN	Rectangular	1 1/4(in) 32(mm)	5.00(in) 127(mm)	15.00(lbs per 1/10in) 26.3(N/mm)
9-2022-11	SPRG.1.250X 5.50-GREEN	Rectangular	1 1/4(in) 32(mm)	5.50(in) 139(mm)	13.50(lbs per 1/10in) 23.6(N/mm)
9-2024-11	SPRG.1.250X 6.00-GREEN	Rectangular	1 1/4(in) 32(mm)	6.00(in) 152(mm)	12.30(lbs per 1/10in) 21.6(N/mm)
9-2028-11	SPRG.1.250X 7.00-GREEN	Rectangular	1 1/4(in) 32(mm)	7.00(in) 178(mm)	10.40(lbs per 1/10in) 18.3(N/mm)
9-2032-11	SPRG.1.250X 8.00-GREEN	Rectangular	1 1/4(in) 32(mm)	8.00(in) 203(mm)	9.10(lbs per 1/10in) 15.9(N/mm)
9-2040-11	SPRG.1.250x10.0-GREEN	Rectangular	1 1/4(in) 32(mm)	10.00(in) 254(mm)	7.20(lbs per 1/10in) 12.5(N/mm)
9-2048-11	SPRG.1.250x12.0-GREEN	Rectangular	1 1/4(in) 32(mm)	12.00(in) 305(mm)	5.90(lbs per 1/10in) 10.4(N/mm)
9-2408-11	SPRG.1.500X 2.00-GREEN	Rectangular	1 1/2(in) 40(mm)	2.00(in) 51(mm)	60.30(lbs per 1/10in) 106.0(N/mm)
Part No.	Description	Wire Type	A - Hole Diameter	C - Free Length	Spring Constant
9-2410-11	SPRG.1.500X 2.50-GREEN	Rectangular	1 1/2(in) 40(mm)	2.50(in) 64(mm)	45.80(lbs per 1/10in) 80.2(N/mm)
9-2412-11	SPRG.1.500X 3.00-GREEN	Rectangular	1 1/2(in) 40(mm)	3.00(in) 76(mm)	37.50(lbs per 1/10in) 65.7(N/mm)
9-2414-11	SPRG.1.500X 3.50-GREEN	Rectangular	1 1/2(in) 40(mm)	3.50(in) 89(mm)	31.80(lbs per 1/10in) 55.7(N/mm)
9-2416-11	SPRG.1.500X 4.00-GREEN	Rectangular	1 1/2(in) 40(mm)	4.00(in) 102(mm)	27.30(lbs per 1/10in) 47.7(N/mm)
9-2418-11	SPRG.1.500X 4.50-GREEN	Rectangular	1 1/2(in) 40(mm)	4.50(in) 115(mm)	24.10(lbs per 1/10in) 42.2(N/mm)
9-2420-11	SPRG.1.500X 5.00-GREEN	Rectangular	1 1/2(in) 40(mm)	5.00(in) 127(mm)	21.60(lbs per 1/10in) 37.8(N/mm)
9-2422-11	SPRG.1.500X 5.50-GREEN	Rectangular	1 1/2(in) 40(mm)	5.50(in) 139(mm)	19.40(lbs per 1/10in) 34.0(N/mm)
9-2424-11	SPRG.1.500X 6.00-GREEN	Rectangular	1 1/2(in) 40(mm)	6.00(in) 152(mm)	17.60(lbs per 1/10in) 30.8(N/mm)
9-2428-11	SPRG.1.500X 7.00-GREEN	Rectangular	1 1/2(in) 40(mm)	7.00(in) 178(mm)	15.00(lbs per 1/10in) 26.2(N/mm)
9-2432-11	SPRG.1.500X 8.00-GREEN	Rectangular	1 1/2(in) 40(mm)	8.00(in) 203(mm)	12.90(lbs per 1/10in) 22.6(N/mm)
9-2440-11	SPRG.1.500x10.0-GREEN	Rectangular	1 1/2(in) 40(mm)	10.00(in) 254(mm)	10.30(lbs per 1/10in) 18.0(N/mm)
9-2448-11	SPRG.1.500x12.0-GREEN	Rectangular	1 1/2(in) 40(mm)	12.00(in) 305(mm)	8.40(lbs per 1/10in) 14.8(N/mm)
9-3210-11	SPRG.2.000X 2.50-GREEN	Rectangular	2(in) 50(mm)	2.50(in) 64(mm)	89.90(lbs per 1/10in) 157.0(N/mm)
9-3212-11	SPRG.2.000X 3.00-GREEN	Rectangular	2(in) 50(mm)	3.00(in) 76(mm)	72.00(lbs per 1/10in) 126.0(N/mm)
9-3214-11	SPRG.2.000X 3.50-GREEN	Rectangular	2(in) 50(mm)	3.50(in) 89(mm)	60.20(lbs per 1/10in) 108.0(N/mm)
9-3216-11	SPRG.2.000X 4.00-GREEN	Rectangular	2(in) 50(mm)	4.00(in) 102(mm)	51.20(lbs per 1/10in) 89.7(N/mm)
9-3218-11	SPRG.2.000X 4.50-GREEN	Rectangular	2(in) 50(mm)	4.50(in) 115(mm)	44.90(lbs per 1/10in) 78.6(N/mm)
9-3220-11	SPRG.2.000X 5.00-GREEN	Rectangular	2(in) 50(mm)	5.00(in) 127(mm)	40.00(lbs per 1/10in) 70.0(N/mm)
9-3222-11	SPRG.2.000X 5.50-GREEN	Rectangular	2(in) 50(mm)	5.50(in) 139(mm)	36.00(lbs per 1/10in) 63.1(N/mm)
9-3224-11	SPRG.2.000X 6.00-GREEN	Rectangular	2(in) 50(mm)	6.00(in) 152(mm)	32.80(lbs per 1/10in) 57.4(N/mm)
9-3228-11	SPRG.2.000X 7.00-GREEN	Rectangular	2(in) 50(mm)	7.00(in) 178(mm)	27.80(lbs per 1/10in) 48.7(N/mm)
9-3232-11	SPRG.2.000X 8.00-GREEN	Rectangular	2(in) 50(mm)	8.00(in) 203(mm)	23.80(lbs per 1/10in) 41.6(N/mm)
9-3240-11	SPRG.2.000x10.0-GREEN	Rectangular	2(in) 50(mm)	10.00(in) 254(mm)	18.80(lbs per 1/10in) 33.0(N/mm)
9-3248-11	SPRG.2.000x12.0-GREEN	Rectangular	2(in) 50(mm)	12.00(in) 305(mm)	15.50(lbs per 1/10in) 27.2(N/mm)
9-4012-11	SPRG.2.500X 3.00-GREEN	Rectangular	2 1/2(in) 63(mm)	3.00(in) 76(mm)	110.00(lbs per 1/10in) 192.0(N/mm)
9-4014-11	SPRG.2.500X 3.50-GREEN	Rectangular	2 1/2(in) 63(mm)	3.50(in) 89(mm)	89.90(lbs per 1/10in) 157.0(N/mm)
9-4016-11	SPRG.2.500X 4.00-GREEN	Rectangular	2 1/2(in) 63(mm)	4.00(in) 102(mm)	76.20(lbs per 1/10in) 133.0(N/mm)
9-4018-11	SPRG.2.500X 4.50-GREEN	Rectangular	2 1/2(in) 63(mm)	4.50(in) 115(mm)	66.00(lbs per 1/10in) 116.0(N/mm)
9-4020-11	SPRG.2.500X 5.00-GREEN	Rectangular	2 1/2(in) 63(mm)	5.00(in) 127(mm)	58.80(lbs per 1/10in) 103.0(N/mm)
9-4024-11	SPRG.2.500X 6.00-GREEN	Rectangular	2 1/2(in) 63(mm)	6.00(in) 152(mm)	47.60(lbs per 1/10in) 83.4(N/mm)
9-4028-11	SPRG.2.500X 7.00-GREEN	Rectangular	2 1/2(in) 63(mm)	7.00(in) 178(mm)	40.00(lbs per 1/10in) 70.0(N/mm)
9-4032-11	SPRG.2.500X 8.00-GREEN	Rectangular	2 1/2(in) 63(mm)	8.00(in) 203(mm)	34.40(lbs per 1/10in) 60.3(N/mm)
9-4040-11	SPRG.2.500x10.0-GREEN	Rectangular	2 1/2(in) 63(mm)	10.00(in) 254(mm)	26.70(lbs per 1/10in) 46.8(N/mm)
9-4048-11	SPRG.2.500x12.0-GREEN	Rectangular	2 1/2(in) 63(mm)	12.00(in) 305(mm)	22.00(lbs per 1/10in) 38.6(N/mm)

DieMax XL Springs: Medium Load (Blue)

Part No.	Description	Wire Type	A - Hole Diameter	C - Free Length	Spring Constant
9-0604-21	SPRG.0.375X1.00-BLUE-MED-HIGH	Rectangular	3/8(in) 10(mm)	1.00(in) 25(mm)	9.30(lbs per 1/10in) 16.2(N/mm)
9-0604-219	RNDSPRG.0.375X1.00-BLUE-MED-HI	Round	3/8(in)	1.00(in)	7.00(lbs per 1/10in)
9-0605-21	SPRG.0.375X1.25-BLUE-MED-HIGH	Rectangular	3/8(in) 10(mm)	1.25(in) 32(mm)	8.00(lbs per 1/10in) 14.0(N/mm)
9-0606-21	SPRG.0.375X1.50-BLUE-MED-HIGH	Rectangular	3/8(in) 10(mm)	1.50(in) 38(mm)	6.70(lbs per 1/10in) 11.7(N/mm)
9-0606-219	RNDSPRG.0.375X1.50-BLUE-MED-HI	Round	3/8(in)	1.50(in)	4.43(lbs per 1/10in)
9-0607-21	SPRG.0.375X1.75-BLUE-MED-HIGH	Rectangular	3/8(in) 10(mm)	1.75(in) 44(mm)	5.60(lbs per 1/10in) 9.9(N/mm)
9-0607-219	RNDSPRG.0.375X1.75-BLUE-MED-HI	Round	3/8(in)	1.75(in)	3.73(lbs per 1/10in)
9-0608-21	SPRG.0.375X2.00-BLUE-MED-HIGH	Rectangular	3/8(in) 10(mm)	2.00(in) 51(mm)	4.92(lbs per 1/10in) 8.6(N/mm)
9-0608-219	RNDSPRG.0.375X2.00-BLUE-MED-HI	Round	3/8(in)	1.25(in)	5.40(lbs per 1/10in)
9-0610-21	SPRG.0.375X2.50-BLUE-MED-HIGH	Rectangular	3/8(in) 10(mm)	2.50(in) 64(mm)	3.87(lbs per 1/10in) 6.8(N/mm)
9-0610-219	RNDSPRG.0.375X2.50-BLUE-MED-HI	Round	3/8(in)	2.50(in)	2.55(lbs per 1/10in)
9-0612-21	SPRG.0.375X3.00-BLUE-MED-HIGH	Rectangular	3/8(in) 10(mm)	3.00(in) 76(mm)	3.25(lbs per 1/10in) 5.7(N/mm)
9-0612-219	RNDSPRG.0.375X3.00-BLUE-MED-HI	Round	3/8(in)	3.00(in)	2.10(lbs per 1/10in)
9-0648-21	SPRG.0.375X12.0-BLUE-MED-HIGH	Rectangular	3/8(in) 10(mm)	12.00(in) 305(mm)	0.76(lbs per 1/10in) 1.3(N/mm)
9-0648-219	RNDSPRG.0.375X12.0-BLUE-MED-HI	Round	3/8(in)	12.00(in)	0.51(lbs per 1/10in)
9-0804-21	SPRG.0.500X1.00-BLUE-MED-HIGH	Rectangular	1/2(in) 12.5(mm)	1.00(in) 25(mm)	16.50(lbs per 1/10in) 28.9(N/mm)
9-0804-219	RNDSPRG.0.500X1.00-BLUE-MED-HI	Round	1/2(in)	1.00(in)	12.40(lbs per 1/10in)
9-0805-21	SPRG.0.500X1.25-BLUE-MED-HIGH	Rectangular	1/2(in) 12.5(mm)	1.25(in) 32(mm)	12.90(lbs per 1/10in) 22.7(N/mm)
9-0805-219	RNDSPRG.0.500X1.25-BLUE-MED-HI	Round	1/2(in)	1.25(in)	9.60(lbs per 1/10in)
9-0806-21	SPRG.0.500X1.50-BLUE-MED-HIGH	Rectangular	1/2(in) 12.5(mm)	1.50(in) 38(mm)	10.90(lbs per 1/10in) 19.1(N/mm)
9-0806-219	RNDSPRG.0.500X1.50-BLUE-MED-HI	Round	1/2(in)	1.50(in)	7.90(lbs per 1/10in)
9-0807-21	SPRG.0.500X1.75-BLUE-MED-HIGH	Rectangular	1/2(in) 12.5(mm)	1.75(in) 44(mm)	9.20(lbs per 1/10in) 16.0(N/mm)
9-0807-219	RNDSPRG.0.500X1.75-BLUE-MED-HI	Round	1/2(in)	1.75(in)	6.60(lbs per 1/10in)
9-0808-21	SPRG.0.500X2.00-BLUE-MED-HIGH	Rectangular	1/2(in) 12.5(mm)	2.00(in) 51(mm)	8.00(lbs per 1/10in) 14.1(N/mm)
9-0808-219	RNDSPRG.0.500X2.00-BLUE-MED-HI	Round	1/2(in)	2.00(in)	5.70(lbs per 1/10in)
9-0810-21	SPRG.0.500X2.50-BLUE-MED-HIGH	Rectangular	1/2(in) 12.5(mm)	2.50(in) 64(mm)	6.30(lbs per 1/10in) 11.0(N/mm)
9-0810-219	RNDSPRG.0.500X2.50-BLUE-MED-HI	Round	1/2(in)	2.50(in)	4.45(lbs per 1/10in)
9-0812-21	SPRG.0.500X3.00-BLUE-MED-HIGH	Rectangular	1/2(in) 12.5(mm)	3.00(in) 76(mm)	5.00(lbs per 1/10in) 8.7(N/mm)
9-0812-219	RNDSPRG.0.500X3.00-BLUE-MED-HI	Round	1/2(in)	3.00(in)	3.66(lbs per 1/10in)
9-0814-21	SPRG.0.500X3.50-BLUE-MED-HIGH	Rectangular	1/2(in) 12.5(mm)	3.50(in) 89(mm)	4.27(lbs per 1/10in) 7.5(N/mm)
9-0814-219	RNDSPRG.0.500X3.50-BLUE-MED-HI	Round	1/2(in)	3.50(in)	3.21(lbs per 1/10in)
9-0848-21	SPRG.0.500x12.0-BLUE-MED-HIGH	Rectangular	1/2(in) 12.5(mm)	12.00(in) 305(mm)	1.24(lbs per 1/10in) 2.2(N/mm)
9-0848-219	RNDSPRG.0.500x12.0-BLUE-MED-HI	Round	1/2(in)	12.00(in)	0.88(lbs per 1/10in)
9-1004-21	SPRG.0.625X1.00-BLUE-MED-HIGH	Rectangular	5/8(in) 16(mm)	1.00(in) 25(mm)	31.80(lbs per 1/10in) 55.6(N/mm)
9-1004-219	RNDSPRG.0.625X1.00-BLUE-MED-HI	Round	5/8(in)	1.00(in)	18.20(lbs per 1/10in)
9-1005-21	SPRG.0.625X1.25-BLUE-MED-HIGH	Rectangular	5/8(in) 16(mm)	1.25(in) 32(mm)	23.00(lbs per 1/10in) 40.3(N/mm)
9-1005-219	RNDSPRG.0.625X1.25-BLUE-MED-HI	Round	5/8(in)	1.25(in)	13.70(lbs per 1/10in)
9-1006-21	SPRG.0.625X1.50-BLUE-MED-HIGH	Rectangular	5/8(in) 16(mm)	1.50(in) 38(mm)	20.10(lbs per 1/10in) 35.2(N/mm)
9-1006-219	RNDSPRG.0.625X1.50-BLUE-MED-HI	Round	5/8(in)	1.50(in)	11.10(lbs per 1/10in)
9-1007-21	SPRG.0.625X1.75-BLUE-MED-HIGH	Rectangular	5/8(in) 16(mm)	1.75(in) 44(mm)	17.40(lbs per 1/10in) 30.5(N/mm)
9-1007-219	RNDSPRG.0.625X1.75-BLUE-MED-HI	Round	5/8(in)	1.75(in)	9.20(lbs per 1/10in)
9-1008-21	SPRG.0.625X2.00-BLUE-MED-HIGH	Rectangular	5/8(in) 16(mm)	2.00(in) 51(mm)	15.40(lbs per 1/10in) 26.9(N/mm)
9-1008-219	RNDSPRG.0.625X2.00-BLUE-MED-HI	Round	5/8(in)	2.00(in)	7.90(lbs per 1/10in)
9-1010-21	SPRG.0.625X2.50-BLUE-MED-HIGH	Rectangular	5/8(in) 16(mm)	2.50(in) 64(mm)	12.00(lbs per 1/10in) 21.0(N/mm)
9-1010-219	RNDSPRG.0.625X2.50-BLUE-MED-HI	Round	5/8(in)	2.50(in)	6.10(lbs per 1/10in)
9-1012-21	SPRG.0.625X3.00-BLUE-MED-HIGH	Rectangular	5/8(in) 16(mm)	3.00(in) 76(mm)	10.10(lbs per 1/10in) 17.8(N/mm)
9-1012-219	RNDSPRG.0.625X3.00-BLUE-MED-HI	Round	5/8(in)	3.00(in)	5.00(lbs per 1/10in)
9-1014-21	SPRG.0.625X3.50-BLUE-MED-HIGH	Rectangular	5/8(in) 16(mm)	3.50(in) 89(mm)	8.70(lbs per 1/10in) 15.2(N/mm)
9-1014-219	RNDSPRG.0.625X3.50-BLUE-MED-HI	Round	5/8(in)	3.50(in)	4.28(lbs per 1/10in)
9-1016-21	SPRG.0.625X4.00-BLUE-MED-HIGH	Rectangular	5/8(in) 16(mm)	4.00(in) 102(mm)	7.60(lbs per 1/10in) 13.2(N/mm)
Part No.	Description	Wire Type	A - Hole Diameter	C - Free Length	Spring Constant
9-1016-219	RNDSPRG.0.625X4.00-BLUE-MED-HI	Round	5/8(in)	4.00(in)	3.73(lbs per 1/10in)
9-1048-21	SPRG.0.625X12.0-BLUE-MED-HIGH	Rectangular	5/8(in) 16(mm)	12.00(in) 305(mm)	2.36(lbs per 1/10in) 4.1(N/mm)
9-1048-219	RNDSPRG.0.625X12.0-BLUE-MED-HI	Round	5/8(in)	12.00(in)	1.19(lbs per 1/10in)
9-1204-21	SPRG.0.750X1.00-BLUE-MED-HIGH	Rectangular	3/4(in) 20(mm)	1.00(in) 25(mm)	51.50(lbs per 1/10in) 90.2(N/mm)
9-1205-21	SPRG.0.750X1.25-BLUE-MED-HIGH	Rectangular	3/4(in) 20(mm)	1.25(in) 32(mm)	38.90(lbs per 1/10in) 68.1(N/mm)
9-1206-21	SPRG.0.750X1.50-BLUE-MED-HIGH	Rectangular	3/4(in) 20(mm)	1.50(in) 38(mm)	31.30(lbs per 1/10in) 54.8(N/mm)
9-1207-21	SPRG.0.750X1.75-BLUE-MED-HIGH	Rectangular	3/4(in) 20(mm)	1.75(in) 44(mm)	25.80(lbs per 1/10in) 45.1(N/mm)
9-1208-21	SPRG.0.750X2.00-BLUE-MED-HIGH	Rectangular	3/4(in) 20(mm)	2.00(in) 51(mm)	22.20(lbs per 1/10in) 38.8(N/mm)
9-1210-21	SPRG.0.750X2.50-BLUE-MED-HIGH	Rectangular	3/4(in) 20(mm)	2.50(in) 64(mm)	17.30(lbs per 1/10in) 30.3(N/mm)
9-1212-21	SPRG.0.750X3.00-BLUE-MED-HIGH	Rectangular	3/4(in) 20(mm)	3.00(in) 76(mm)	14.10(lbs per 1/10in) 24.7(N/mm)
9-1214-21	SPRG.0.750X3.50-BLUE-MED-HIGH	Rectangular	3/4(in) 20(mm)	3.50(in) 89(mm)	12.20(lbs per 1/10in) 21.3(N/mm)
9-1216-21	SPRG.0.750X4.00-BLUE-MED-HIGH	Rectangular	3/4(in) 20(mm)	4.00(in) 102(mm)	10.60(lbs per 1/10in) 18.6(N/mm)
9-1218-21	SPRG.0.750X4.50-BLUE-MED-HIGH	Rectangular	3/4(in) 20(mm)	4.50(in) 115(mm)	9.30(lbs per 1/10in) 16.3(N/mm)
9-1220-21	SPRG.0.750X5.00-BLUE-MED-HIGH	Rectangular	3/4(in) 20(mm)	5.00(in) 127(mm)	8.30(lbs per 1/10in) 14.6(N/mm)
9-1222-21	SPRG.0.750X5.50-BLUE-MED-HIGH	Rectangular	3/4(in) 20(mm)	5.50(in) 139(mm)	7.50(lbs per 1/10in) 13.2(N/mm)
9-1224-21	SPRG.0.750X6.00-BLUE-MED-HIGH	Rectangular	3/4(in) 20(mm)	6.00(in) 152(mm)	6.90(lbs per 1/10in) 12.1(N/mm)
9-1248-21	SPRG.0.750x12.0-BLUE-MED-HIGH	Rectangular	3/4(in) 20(mm)	12.00(in) 305(mm)	3.46(lbs per 1/10in) 6.1(N/mm)
9-1604-21	SPRG.1.000X1.00-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	1.00(in) 25(mm)	94.90(lbs per 1/10in) 166.0(N/mm)
9-1605-21	SPRG.1.000X1.25-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	1.25(in) 32(mm)	71.20(lbs per 1/10in) 125.0(N/mm)
9-1606-21	SPRG.1.000X1.50-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	1.50(in) 38(mm)	56.30(lbs per 1/10in) 98.6(N/mm)
9-1607-21	SPRG.1.000X1.75-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	1.75(in) 44(mm)	47.50(lbs per 1/10in) 83.1(N/mm)
9-1608-21	SPRG.1.000X2.00-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	2.00(in) 51(mm)	41.00(lbs per 1/10in) 71.8(N/mm)
9-1610-21	SPRG.1.000X2.50-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	2.50(in) 64(mm)	31.40(lbs per 1/10in) 55.1(N/mm)
9-1612-21	SPRG.1.000X3.00-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	3.00(in) 76(mm)	25.80(lbs per 1/10in) 45.1(N/mm)
9-1614-21	SPRG.1.000X3.50-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	3.50(in) 89(mm)	21.60(lbs per 1/10in) 37.9(N/mm)
9-1616-21	SPRG.1.000X4.00-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	4.00(in) 102(mm)	18.80(lbs per 1/10in) 32.9(N/mm)
9-1618-21	SPRG.1.000X4.50-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	4.50(in) 115(mm)	16.70(lbs per 1/10in) 29.2(N/mm)
9-1620-21	SPRG.1.000X5.00-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	5.00(in) 127(mm)	15.00(lbs per 1/10in) 26.2(N/mm)
9-1622-21	SPRG.1.000X5.50-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	5.50(in) 139(mm)	13.50(lbs per 1/10in) 23.7(N/mm)
9-1624-21	SPRG.1.000X6.00-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	6.00(in) 152(mm)	12.40(lbs per 1/10in) 21.6(N/mm)
9-1628-21	SPRG.1.000X7.00-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	7.00(in) 178(mm)	10.50(lbs per 1/10in) 18.4(N/mm)
9-1632-21	SPRG.1.000X8.00-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	8.00(in) 203(mm)	9.10(lbs per 1/10in) 15.9(N/mm)
9-1648-21	SPRG.1.000x12.0-BLUE-MED-HIGH	Rectangular	1(in) 25(mm)	12.00(in) 305(mm)	6.00(lbs per 1/10in) 10.4(N/mm)
9-2006-21	SPRG.1.250X1.50-BLUE-MED-HIGH	Rectangular	1 1/4(in) 32(mm)	1.50(in) 38(mm)	94.80(lbs per 1/10in) 166.0(N/mm)
9-2007-21	SPRG.1.250X1.75-BLUE-MED-HIGH	Rectangular	1 1/4(in) 32(mm)	1.75(in) 44(mm)	77.90(lbs per 1/10in) 136.0(N/mm)
9-2008-21	SPRG.1.250X2.00-BLUE-MED-HIGH	Rectangular	1 1/4(in) 32(mm)	2.00(in) 51(mm)	66.30(lbs per 1/10in) 116.0(N/mm)
9-2010-21	SPRG.1.250X2.50-BLUE-MED-HIGH	Rectangular	1 1/4(in) 32(mm)	2.50(in) 64(mm)	50.10(lbs per 1/10in) 87.7(N/mm)
9-2012-21	SPRG.1.250X3.00-BLUE-MED-HIGH	Rectangular	1 1/4(in) 32(mm)	3.00(in) 76(mm)	40.50(lbs per 1/10in) 71.0(N/mm)
9-2014-21	SPRG.1.250X3.50-BLUE-MED-HIGH	Rectangular	1 1/4(in) 32(mm)	3.50(in) 89(mm)	34.20(lbs per 1/10in) 59.9(N/mm)
9-2016-21	SPRG.1.250X4.00-BLUE-MED-HIGH	Rectangular	1 1/4(in) 32(mm)	4.00(in) 102(mm)	29.60(lbs per 1/10in) 51.9(N/mm)
9-2018-21	SPRG.1.250X4.50-BLUE-MED-HIGH	Rectangular	1 1/4(in) 32(mm)	4.50(in) 115(mm)	26.30(lbs per 1/10in) 46.1(N/mm)
9-2020-21	SPRG.1.250X5.00-BLUE-MED-HIGH	Rectangular	1 1/4(in) 32(mm)	5.00(in) 127(mm)	23.70(lbs per 1/10in) 41.5(N/mm)
9-2022-21	SPRG.1.250X5.50-BLUE-MED-HIGH	Rectangular	1 1/4(in) 32(mm)	5.50(in) 139(mm)	21.70(lbs per 1/10in) 37.5(N/mm)
9-2024-21	SPRG.1.250X6.00-BLUE-MED-HIGH	Rectangular	1 1/4(in) 32(mm)	6.00(in) 152(mm)	19.50(lbs per 1/10in) 34.1(N/mm)
9-2028-21	SPRG.1.250X7.00-BLUE-MED-HIGH	Rectangular	1 1/4(in) 32(mm)	7.00(in) 178(mm)	16.60(lbs per 1/10in) 29.0(N/mm)
9-2032-21	SPRG.1.250X8.00-BLUE-MED-HIGH	Rectangular	1 1/4(in) 32(mm)	8.00(in) 203(mm)	14.40(lbs per 1/10in) 25.2(N/mm)
9-2040-21	SPRG.1.250x10.0-BLUE-MED-HIGH	Rectangular	1 1/4(in) 32(mm)	10.00(in) 254(mm)	11.40(lbs per 1/10in) 20.0(N/mm)
9-2048-21	SPRG.1.250x12.0-BLUE-MED-HIGH	Rectangular	1 1/4(in) 32(mm)	12.00(in) 305(mm)	9.50(lbs per 1/10in) 16.6(N/mm)
9-2408-21	SPRG.1.500X2.00-BLUE-MED-HIGH	Rectangular	1 1/2(in) 40(mm)	2.00(in) 51(mm)	97.40(lbs per 1/10in) 170.0(N/mm)
9-2410-21	SPRG.1.500X2.50-BLUE-MED-HIGH	Rectangular	1 1/2(in) 40(mm)	2.50(in) 64(mm)	73.50(lbs per 1/10in) 129.0(N/mm)
Part No.	Description	Wire Type	A - Hole Diameter	C - Free Length	Spring Constant
9-2412-21	SPRG.1.500X3.00-BLUE-MED-HIGH	Rectangular	1 1/2(in) 40(mm)	3.00(in) 76(mm)	60.10(lbs per 1/10in) 105.0(N/mm)
9-2414-21	SPRG.1.500X3.50-BLUE-MED-HIGH	Rectangular	1 1/2(in) 40(mm)	3.50(in) 89(mm)	50.10(lbs per 1/10in) 87.7(N/mm)
9-2416-21	SPRG.1.500X4.00-BLUE-MED-HIGH	Rectangular	1 1/2(in) 40(mm)	4.00(in) 102(mm)	43.40(lbs per 1/10in) 76.0(N/mm)
9-2418-21	SPRG.1.500X4.50-BLUE-MED-HIGH	Rectangular	1 1/2(in) 40(mm)	4.50(in) 115(mm)	37.90(lbs per 1/10in) 66.4(N/mm)
9-2420-21	SPRG.1.500X5.00-BLUE-MED-HIGH	Rectangular	1 1/2(in) 40(mm)	5.00(in) 127(mm)	34.00(lbs per 1/10in) 59.6(N/mm)
9-2422-21	SPRG.1.500X5.50-BLUE-MED-HIGH	Rectangular	1 1/2(in) 40(mm)	5.50(in) 139(mm)	30.60(lbs per 1/10in) 53.5(N/mm)
9-2424-21	SPRG.1.500X6.00-BLUE-MED-HIGH	Rectangular	1 1/2(in) 40(mm)	6.00(in) 152(mm)	27.90(lbs per 1/10in) 48.9(N/mm)
9-2428-21	SPRG.1.500X7.00-BLUE-MED-HIGH	Rectangular	1 1/2(in) 40(mm)	7.00(in) 178(mm)	23.70(lbs per 1/10in) 41.5(N/mm)
9-2432-21	SPRG.1.500X8.00-BLUE-MED-HIGH	Rectangular	1 1/2(in) 40(mm)	8.00(in) 203(mm)	20.60(lbs per 1/10in) 36.1(N/mm)
9-2440-21	SPRG.1.500x10.0-BLUE-MED-HIGH	Rectangular	1 1/2(in) 40(mm)	10.00(in) 254(mm)	16.50(lbs per 1/10in) 28.8(N/mm)
9-2448-21	SPRG.1.500x12.0-BLUE-MED-HIGH	Rectangular	1 1/2(in) 40(mm)	12.00(in) 305(mm)	13.60(lbs per 1/10in) 23.7(N/mm)
9-3210-21	SPRG.2.000X2.50-BLUE-MED-HIGH	Rectangular	2(in) 50(mm)	2.50(in) 64(mm)	121.00(lbs per 1/10in) 212.0(N/mm)
9-3212-21	SPRG.2.000X3.00-BLUE-MED-HIGH	Rectangular	2(in) 50(mm)	3.00(in) 76(mm)	95.60(lbs per 1/10in) 167.0(N/mm)
9-3214-21	SPRG.2.000X3.50-BLUE-MED-HIGH	Rectangular	2(in) 50(mm)	3.50(in) 89(mm)	79.80(lbs per 1/10in) 140.0(N/mm)
9-3216-21	SPRG.2.000X4.00-BLUE-MED-HIGH	Rectangular	2(in) 50(mm)	4.00(in) 102(mm)	69.60(lbs per 1/10in) 122.0(N/mm)
9-3218-21	SPRG.2.000X4.50-BLUE-MED-HIGH	Rectangular	2(in) 50(mm)	4.50(in) 115(mm)	61.20(lbs per 1/10in) 107.0(N/mm)
9-3220-21	SPRG.2.000X5.00-BLUE-MED-HIGH	Rectangular	2(in) 50(mm)	5.00(in) 127(mm)	54.00(lbs per 1/10in) 94.5(N/mm)
9-3222-21	SPRG.2.000X5.50-BLUE-MED-HIGH	Rectangular	2(in) 50(mm)	5.50(in) 139(mm)	48.80(lbs per 1/10in) 85.5(N/mm)
9-3224-21	SPRG.2.000X6.00-BLUE-MED-HIGH	Rectangular	2(in) 50(mm)	6.00(in) 152(mm)	44.50(lbs per 1/10in) 78.0(N/mm)
9-3228-21	SPRG.2.000X7.00-BLUE-MED-HIGH	Rectangular	2(in) 50(mm)	7.00(in) 178(mm)	37.90(lbs per 1/10in) 66.4(N/mm)
9-3232-21	SPRG.2.000X8.00-BLUE-MED-HIGH	Rectangular	2(in) 50(mm)	8.00(in) 203(mm)	32.80(lbs per 1/10in) 57.4(N/mm)
9-3236-21	SPRG.2.000X9.00-BLUE-MED-HIGH	Rectangular	2(in) 50(mm)	9.00(in) 229(mm)	29.10(lbs per 1/10in) 50.9(N/mm)
9-3240-21	SPRG.2.000x10.0-BLUE-MED-HIGH	Rectangular	2(in) 50(mm)	10.00(in) 254(mm)	26.10(lbs per 1/10in) 45.7(N/mm)
9-3248-21	SPRG.2.000x12.0-BLUE-MED-HIGH	Rectangular	2(in) 50(mm)	12.00(in) 305(mm)	21.50(lbs per 1/10in) 37.7(N/mm)
9-4012-21	SPRG.2.500X3.00-BLUE-MED-HIGH	Rectangular	2 1/2(in) 63(mm)	3.00(in) 76(mm)	174.00(lbs per 1/10in) 304.0(N/mm)
9-4014-21	SPRG.2.500X3.50-BLUE-MED-HIGH	Rectangular	2 1/2(in) 63(mm)	3.50(in) 89(mm)	143.00(lbs per 1/10in) 250.0(N/mm)
9-4016-21	SPRG.2.500X4.00-BLUE-MED-HIGH	Rectangular	2 1/2(in) 63(mm)	4.00(in) 102(mm)	121.00(lbs per 1/10in) 212.0(N/mm)
9-4018-21	SPRG.2.500X4.50-BLUE-MED-HIGH	Rectangular	2 1/2(in) 63(mm)	4.50(in) 115(mm)	106.00(lbs per 1/10in) 186.0(N/mm)
9-4020-21	SPRG.2.500X5.00-BLUE-MED-HIGH	Rectangular	2 1/2(in) 63(mm)	5.00(in) 127(mm)	93.70(lbs per 1/10in) 164.0(N/mm)
9-4024-21	SPRG.2.500X6.00-BLUE-MED-HIGH	Rectangular	2 1/2(in) 63(mm)	6.00(in) 152(mm)	75.90(lbs per 1/10in) 133.0(N/mm)
9-4028-21	SPRG.2.500X7.00-BLUE-MED-HIGH	Rectangular	2 1/2(in) 63(mm)	7.00(in) 178(mm)	63.80(lbs per 1/10in) 112.0(N/mm)
9-4032-21	SPRG.2.500X8.00-BLUE-MED-HIGH	Rectangular	2 1/2(in) 63(mm)	8.00(in) 203(mm)	55.00(lbs per 1/10in) 96.3(N/mm)
9-4036-21	SPRG.2.500X9.00-BLUE-MED-HIGH	Rectangular	2 1/2(in) 63(mm)	9.00(in) 229(mm)	48.80(lbs per 1/10in) 85.5(N/mm)
9-4040-21	SPRG.2.500x10.0-BLUE-MED-HIGH	Rectangular	2 1/2(in) 63(mm)	10.00(in) 254(mm)	43.90(lbs per 1/10in) 76.8(N/mm)
9-4048-21	SPRG.2.500x12.0-BLUE-MED-HIGH	Rectangular	2 1/2(in) 63(mm)	12.00(in) 305(mm)	36.20(lbs per 1/10in) 63.5(N/mm

DieMax XL Springs: Heavy Load (Red)

Part No.	Description	Wire Type	A - Hole Diameter	C - Free Length	Spring Constant
9-0604-26	SPRG.0.375X1.00-RED-HVY-DUTY	Rectangular	3/8(in) 10(mm)	1.00(in) 25(mm)	12.60(lbs per 1/10in) 22.1(N/mm)
9-0604-269	RNDSPRG.0.375X1.00-RED-HVYDUTY	Round	3/8(in)	1.00(in)	11.80(lbs per 1/10in)
9-0605-26	SPRG.0.375X1.25-RED-HVY-DUTY	Rectangular	3/8(in) 10(mm)	1.25(in) 32(mm)	10.00(lbs per 1/10in) 17.5(N/mm)
9-0605-269	RNDSPRG.0.375X1.25-RED-HVYDUTY	Round	3/8(in)	1.25(in)	9.20(lbs per 1/10in)
9-0606-26	SPRG.0.375X1.50-RED-HVY-DUTY	Rectangular	3/8(in) 10(mm)	1.50(in) 38(mm)	9.30(lbs per 1/10in) 16.3(N/mm)
9-0606-269	RNDSPRG.0.375X1.50-RED-HVYDUTY	Round	3/8(in)	1.50(in)	7.40(lbs per 1/10in)
9-0607-26	SPRG.0.375X1.75-RED-HVY-DUTY	Rectangular	3/8(in) 10(mm)	1.75(in) 44(mm)	8.00(lbs per 1/10in) 14.0(N/mm)
9-0607-269	RNDSPRG.0.375X1.75-RED-HVYDUTY	Round	3/8(in)	1.75(in)	6.20(lbs per 1/10in)
9-0608-26	SPRG.0.375X2.00-RED-HVY-DUTY	Rectangular	3/8(in) 10(mm)	2.00(in) 51(mm)	6.80(lbs per 1/10in) 12.0(N/mm)
9-0608-269	RNDSPRG.0.375X2.00-RED-HVYDUTY	Round	3/8(in)	2.00(in)	5.50(lbs per 1/10in)
9-0610-26	SPRG.0.375X2.50-RED-HVY-DUTY	Rectangular	3/8(in) 10(mm)	2.50(in) 64(mm)	5.50(lbs per 1/10in) 9.6(N/mm)
9-0610-269	RNDSPRG.0.375X2.50-RED-HVYDUTY	Round	3/8(in)	2.50(in)	4.38(lbs per 1/10in)
9-0612-26	SPRG.0.375X3.00-RED-HVY-DUTY	Rectangular	3/8(in) 10(mm)	3.00(in) 76(mm)	4.34(lbs per 1/10in) 7.6(N/mm)
9-0612-269	RNDSPRG.0.375X3.00-RED-HVYDUTY	Round	3/8(in)	3.00(in)	3.59(lbs per 1/10in)
9-0648-26	SPRG.0.375X12.0-RED-HVY-DUTY	Rectangular	3/8(in) 10(mm)	12.00(in) 305(mm)	1.07(lbs per 1/10in) 1.9(N/mm)
9-0648-269	RNDSPRG.0.375X12.0-RED-HVYDUTY	Round	3/8(in)	12.00(in)	0.87(lbs per 1/10in)
9-0804-26	SPRG.0.500X1.00-RED-HVY-DUTY	Rectangular	1/2(in) 12.5(mm)	1.00(in) 25(mm)	23.60(lbs per 1/10in) 41.3(N/mm)
9-0804-269	RNDSPRG.0.500X1.00-RED-HVYDUTY	Round	1/2(in)	1.00(in)	21.40(lbs per 1/10in)
9-0805-26	SPRG.0.500X1.25-RED-HVY-DUTY	Rectangular	1/2(in) 12.5(mm)	1.25(in) 32(mm)	18.80(lbs per 1/10in) 32.9(N/mm)
9-0805-269	RNDSPRG.0.500X1.25-RED-HVYDUTY	Round	1/2(in)	1.25(in)	16.50(lbs per 1/10in)
9-0806-26	SPRG.0.500X1.50-RED-HVY-DUTY	Rectangular	1/2(in) 12.5(mm)	1.50(in) 38(mm)	15.50(lbs per 1/10in) 27.2(N/mm)
9-0806-269	RNDSPRG.0.500X1.50-RED-HVYDUTY	Round	1/2(in)	1.50(in)	13.40(lbs per 1/10in)
9-0807-26	SPRG.0.500X1.75-RED-HVY-DUTY	Rectangular	1/2(in) 12.5(mm)	1.75(in) 44(mm)	13.30(lbs per 1/10in) 23.3(N/mm)
9-0807-269	RNDSPRG.0.500X1.75-RED-HVYDUTY	Round	1/2(in)	1.75(in)	11.20(lbs per 1/10in)
9-0808-26	SPRG.0.500X2.00-RED-HVY-DUTY	Rectangular	1/2(in) 12.5(mm)	2.00(in) 51(mm)	11.40(lbs per 1/10in) 20.0(N/mm)
9-0808-269	RNDSPRG.0.500X2.00-RED-HVYDUTY	Round	1/2(in)	2.00(in)	9.90(lbs per 1/10in)
9-0810-26	SPRG.0.500X2.50-RED-HVY-DUTY	Rectangular	1/2(in) 12.5(mm)	2.50(in) 64(mm)	8.70(lbs per 1/10in) 15.2(N/mm)
9-0810-269	RNDSPRG.0.500X2.50-RED-HVYDUTY	Round	1/2(in)	2.50(in)	7.70(lbs per 1/10in)
9-0812-26	SPRG.0.500X3.00-RED-HVY-DUTY	Rectangular	1/2(in) 12.5(mm)	3.00(in) 76(mm)	7.70(lbs per 1/10in) 13.6(N/mm)
9-0812-269	RNDSPRG.0.500X3.00-RED-HVYDUTY	Round	1/2(in)	3.00(in)	6.40(lbs per 1/10in)
9-0814-26	SPRG.0.500X3.50-RED-HVY-DUTY	Rectangular	1/2(in) 12.5(mm)	3.50(in) 89(mm)	6.20(lbs per 1/10in) 10.9(N/mm)
9-0814-269	RNDSPRG.0.500X3.50-RED-HVYDUTY	Round	1/2(in)	3.50(in)	5.40(lbs per 1/10in)
9-0848-26	SPRG.0.500x12.0-RED-HVY-DUTY	Rectangular	1/2(in) 12.5(mm)	12.00(in) 305(mm)	1.77(lbs per 1/10in) 3.1(N/mm)
9-0848-269	RNDSPRG.0.500x12.0-RED-HVYDUTY	Round	1/2(in)	12.00(in)	1.52(lbs per 1/10in)
9-1004-26	SPRG.0.625X1.00-RED-HVY-DUTY	Rectangular	5/8(in) 16(mm)	1.00(in) 25(mm)	43.10(lbs per 1/10in) 75.5(N/mm)
9-1004-269	RNDSPRG.0.625X1.00-RED-HVYDUTY	Round	5/8(in)	1.00(in)	46.60(lbs per 1/10in)
9-1005-26	SPRG.0.625X1.25-RED-HVY-DUTY	Rectangular	5/8(in) 16(mm)	1.25(in) 32(mm)	24.80(lbs per 1/10in) 60.9(N/mm)
9-1005-269	RNDSPRG.0.625X1.25-RED-HVYDUTY	Round	5/8(in)	1.25(in)	35.00(lbs per 1/10in)
9-1006-26	SPRG.0.625X1.50-RED-HVY-DUTY	Rectangular	5/8(in) 16(mm)	1.50(in) 38(mm)	27.80(lbs per 1/10in) 48.7(N/mm)
9-1006-269	RNDSPRG.0.625X1.50-RED-HVYDUTY	Round	5/8(in)	1.50(in)	28.50(lbs per 1/10in)
9-1007-26	SPRG.0.625X1.75-RED-HVY-DUTY	Rectangular	5/8(in) 16(mm)	1.75(in) 44(mm)	24.70(lbs per 1/10in) 43.3(N/mm)
9-1007-269	RNDSPRG.0.625X1.75-RED-HVYDUTY	Round	5/8(in)	1.75(in)	23.30(lbs per 1/10in)
9-1008-26	SPRG.0.625X2.00-RED-HVY-DUTY	Rectangular	5/8(in) 16(mm)	2.00(in) 51(mm)	20.50(lbs per 1/10in) 36.0(N/mm)
9-1008-269	RNDSPRG.0.625X2.00-RED-HVYDUTY	Round	5/8(in)	2.00(in)	20.30(lbs per 1/10in)
9-1010-26	SPRG.0.625X2.50-RED-HVY-DUTY	Rectangular	5/8(in) 16(mm)	2.50(in) 64(mm)	16.50(lbs per 1/10in) 28.9(N/mm)
9-1010-269	RNDSPRG.0.625X2.50-RED-HVYDUTY	Round	5/8(in)	2.50(in)	15.90(lbs per 1/10in)
9-1012-26	SPRG.0.625X3.00-RED-HVY-DUTY	Rectangular	5/8(in) 16(mm)	3.00(in) 76(mm)	14.00(lbs per 1/10in) 24.5(N/mm)
9-1012-269	RNDSPRG.0.625X3.00-RED-HVYDUTY	Round	5/8(in)	3.00(in)	13.00(lbs per 1/10in)
9-1014-26	SPRG.0.625X3.50-RED-HVY-DUTY	Rectangular	5/8(in) 16(mm)	3.50(in) 89(mm)	11.90(lbs per 1/10in) 20.9(N/mm)
9-1014-269	RNDSPRG.0.625X3.50-RED-HVYDUTY	Round	5/8(in)	3.50(in)	11.20(lbs per 1/10in)
Part No.	Description	Wire Type	A - Hole Diameter	C - Free Length	Spring Constant
9-1016-26	SPRG.0.625X4.00-RED-HVY-DUTY	Rectangular	5/8(in) 16(mm)	4.00(in) 102(mm)	10.40(lbs per 1/10in) 18.2(N/mm)
9-1016-269	RNDSPRG.0.625X4.00-RED-HVYDUTY	Round	5/8(in)	4.00(in)	9.70(lbs per 1/10in)
9-1048-26	SPRG.0.625X12.0-RED-HVY-DUTY	Rectangular	5/8(in) 16(mm)	12.00(in) 305(mm)	3.33(lbs per 1/10in) 5.8(N/mm)
9-1048-269	RNDSPRG.0.625X12.0-RED-HVYDUTY	Round	5/8(in)	12.00(in)	3.09(lbs per 1/10in)
9-1204-26	SPRG.0.750X1.00-RED-HVY-DUTY	Rectangular	3/4(in) 20(mm)	1.00(in) 25(mm)	137.00(lbs per 1/10in) 240.0(N/mm)
9-1205-26	SPRG.0.750X1.25-RED-HVY-DUTY	Rectangular	3/4(in) 20(mm)	1.25(in) 32(mm)	103.00(lbs per 1/10in) 180.0(N/mm)
9-1206-26	SPRG.0.750X1.50-RED-HVY-DUTY	Rectangular	3/4(in) 20(mm)	1.50(in) 38(mm)	82.20(lbs per 1/10in) 144.0(N/mm)
9-1207-26	SPRG.0.750X1.75-RED-HVY-DUTY	Rectangular	3/4(in) 20(mm)	1.75(in) 44(mm)	68.50(lbs per 1/10in) 120.0(N/mm)
9-1208-26	SPRG.0.750X2.00-RED-HVY-DUTY	Rectangular	3/4(in) 20(mm)	2.00(in) 51(mm)	57.80(lbs per 1/10in) 101.0(N/mm)
9-1210-26	SPRG.0.750X2.50-RED-HVY-DUTY	Rectangular	3/4(in) 20(mm)	2.50(in) 64(mm)	44.00(lbs per 1/10in) 77.1(N/mm)
9-1212-26	SPRG.0.750X3.00-RED-HVY-DUTY	Rectangular	3/4(in) 20(mm)	3.00(in) 76(mm)	36.20(lbs per 1/10in) 63.5(N/mm)
9-1214-26	SPRG.0.750X3.50-RED-HVY-DUTY	Rectangular	3/4(in) 20(mm)	3.50(in) 89(mm)	30.80(lbs per 1/10in) 53.9(N/mm)
9-1216-26	SPRG.0.750X4.00-RED-HVY-DUTY	Rectangular	3/4(in) 20(mm)	4.00(in) 102(mm)	26.80(lbs per 1/10in) 46.9(N/mm)
9-1218-26	SPRG.0.750X4.50-RED-HVY-DUTY	Rectangular	3/4(in) 20(mm)	4.50(in) 115(mm)	23.70(lbs per 1/10in) 41.5(N/mm)
9-1220-26	SPRG.0.750X5.00-RED-HVY-DUTY	Rectangular	3/4(in) 20(mm)	5.00(in) 127(mm)	21.20(lbs per 1/10in) 37.2(N/mm)
9-1222-26	SPRG.0.750X5.50-RED-HVY-DUTY	Rectangular	3/4(in) 20(mm)	5.50(in) 139(mm)	19.30(lbs per 1/10in) 33.7(N/mm)
9-1224-26	SPRG.0.750X6.00-RED-HVY-DUTY	Rectangular	3/4(in) 20(mm)	6.00(in) 152(mm)	17.60(lbs per 1/10in) 30.8(N/mm)
9-1248-26	SPRG.0.750x12.0-RED-HVY-DUTY	Rectangular	3/4(in) 20(mm)	12.00(in) 305(mm)	8.60(lbs per 1/10in) 15.1(N/mm)
9-1604-26	SPRG.1.000X1.00-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	1.00(in) 25(mm)	215.00(lbs per 1/10in) 376.0(N/mm)
9-1605-26	SPRG.1.000X1.25-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	1.25(in) 32(mm)	163.00(lbs per 1/10in) 285.0(N/mm)
9-1606-26	SPRG.1.000X1.50-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	1.50(in) 38(mm)	127.00(lbs per 1/10in) 222.0(N/mm)
9-1607-26	SPRG.1.000X1.75-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	1.75(in) 44(mm)	109.00(lbs per 1/10in) 190.0(N/mm)
9-1608-26	SPRG.1.000X2.00-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	2.00(in) 51(mm)	89.40(lbs per 1/10in) 157.0(N/mm)
9-1610-26	SPRG.1.000X2.50-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	2.50(in) 64(mm)	69.10(lbs per 1/10in) 121.0(N/mm)
9-1612-26	SPRG.1.000X3.00-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	3.00(in) 76(mm)	57.00(lbs per 1/10in) 100.0(N/mm)
9-1614-26	SPRG.1.000X3.50-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	3.50(in) 89(mm)	48.00(lbs per 1/10in) 84.1(N/mm)
9-1616-26	SPRG.1.000X4.00-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	4.00(in) 102(mm)	41.80(lbs per 1/10in) 73.3(N/mm)
9-1618-26	SPRG.1.000X4.50-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	4.50(in) 115(mm)	37.10(lbs per 1/10in) 64.9(N/mm)
9-1620-26	SPRG.1.000X5.00-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	5.00(in) 127(mm)	33.10(lbs per 1/10in) 57.9(N/mm)
9-1622-26	SPRG.1.000X5.50-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	5.50(in) 139(mm)	30.00(lbs per 1/10in) 52.6(N/mm)
9-1624-26	SPRG.1.000X6.00-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	6.00(in) 152(mm)	27.50(lbs per 1/10in) 48.1(N/mm)
9-1628-26	SPRG.1.000X7.00-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	7.00(in) 178(mm)	23.50(lbs per 1/10in) 41.2(N/mm)
9-1632-26	SPRG.1.000X8.00-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	8.00(in) 203(mm)	20.50(lbs per 1/10in) 35.8(N/mm)
9-1648-26	SPRG.1.000x12.0-RED-HVY-DUTY	Rectangular	1(in) 25(mm)	12.00(in) 305(mm)	13.80(lbs per 1/10in) 24.2(N/mm)
9-2006-26	SPRG.1.250X1.50-RED-HVY-DUTY	Rectangular	1 1/4(in) 32(mm)	1.50(in) 38(mm)	223.00(lbs per 1/10in) 390.0(N/mm)
9-2007-26	SPRG.1.250X1.75-RED-HVY-DUTY	Rectangular	1 1/4(in) 32(mm)	1.75(in) 44(mm)	182.00(lbs per 1/10in) 319.0(N/mm)
9-2008-26	SPRG.1.250X2.00-RED-HVY-DUTY	Rectangular	1 1/4(in) 32(mm)	2.00(in) 51(mm)	154.00(lbs per 1/10in) 270.0(N/mm)
9-2010-26	SPRG.1.250X2.50-RED-HVY-DUTY	Rectangular	1 1/4(in) 32(mm)	2.50(in) 64(mm)	117.00(lbs per 1/10in) 204.0(N/mm)
9-2012-26	SPRG.1.250X3.00-RED-HVY-DUTY	Rectangular	1 1/4(in) 32(mm)	3.00(in) 76(mm)	94.70(lbs per 1/10in) 166.0(N/mm)
9-2014-26	SPRG.1.250X3.50-RED-HVY-DUTY	Rectangular	1 1/4(in) 32(mm)	3.50(in) 89(mm)	80.10(lbs per 1/10in) 140.0(N/mm)
9-2016-26	SPRG.1.250X4.00-RED-HVY-DUTY	Rectangular	1 1/4(in) 32(mm)	4.00(in) 102(mm)	69.10(lbs per 1/10in) 121.0(N/mm)
9-2018-26	SPRG.1.250X4.50-RED-HVY-DUTY	Rectangular	1 1/4(in) 32(mm)	4.50(in) 115(mm)	60.70(lbs per 1/10in) 106.0(N/mm)
9-2020-26	SPRG.1.250X5.00-RED-HVY-DUTY	Rectangular	1 1/4(in) 32(mm)	5.00(in) 127(mm)	54.70(lbs per 1/10in) 95.7(N/mm)
9-2022-26	SPRG.1.250X5.50-RED-HVY-DUTY	Rectangular	1 1/4(in) 32(mm)	5.50(in) 139(mm)	49.30(lbs per 1/10in) 86.3(N/mm)
9-2024-26	SPRG.1.250X6.00-RED-HVY-DUTY	Rectangular	1 1/4(in) 32(mm)	6.00(in) 152(mm)	44.90(lbs per 1/10in) 78.6(N/mm)
9-2028-26	SPRG.1.250X7.00-RED-HVY-DUTY	Rectangular	1 1/4(in) 32(mm)	7.00(in) 178(mm)	38.10(lbs per 1/10in) 66.7(N/mm)
9-2032-26	SPRG.1.250X8.00-RED-HVY-DUTY	Rectangular	1 1/4(in) 32(mm)	8.00(in) 203(mm)	33.00(lbs per 1/10in) 57.9(N/mm)
9-2040-26	SPRG.1.250x10.0-RED-HVY-DUTY	Rectangular	1 1/4(in) 32(mm)	10.00(in) 254(mm)	26.40(lbs per 1/10in) 46.2(N/mm)
9-2048-26	SPRG.1.250x12.0-RED-HVY-DUTY	Rectangular	1 1/4(in) 32(mm)	12.00(in) 305(mm)	21.80(lbs per 1/10in) 38.7(N/mm)
9-2408-26	SPRG.1.500X2.00-RED-HVY-DUTY	Rectangular	1 1/2(in) 40(mm)	2.00(in) 51(mm)	208.00(lbs per 1/10in) 363.0(N/mm)
Part No.	Description	Wire Type	A - Hole Diameter	C - Free Length	Spring Constant
9-2410-26	SPRG.1.500X2.50-RED-HVY-DUTY	Rectangular	1 1/2(in) 40(mm)	2.50(in) 64(mm)	153.00(lbs per 1/10in) 268.0(N/mm)
9-2412-26	SPRG.1.500X3.00-RED-HVY-DUTY	Rectangular	1 1/2(in) 40(mm)	3.00(in) 76(mm)	125.00(lbs per 1/10in) 219.0(N/mm)
9-2414-26	SPRG.1.500X3.50-RED-HVY-DUTY	Rectangular	1 1/2(in) 40(mm)	3.50(in) 89(mm)	105.00(lbs per 1/10in) 185.0(N/mm)
9-2416-26	SPRG.1.500X4.00-RED-HVY-DUTY	Rectangular	1 1/2(in) 40(mm)	4.00(in) 102(mm)	90.60(lbs per 1/10in) 159.0(N/mm)
9-2418-26	SPRG.1.500X4.50-RED-HVY-DUTY	Rectangular	1 1/2(in) 40(mm)	4.50(in) 115(mm)	80.40(lbs per 1/10in) 141.0(N/mm)
9-2420-26	SPRG.1.500X5.00-RED-HVY-DUTY	Rectangular	1 1/2(in) 40(mm)	5.00(in) 127(mm)	71.50(lbs per 1/10in) 125.0(N/mm)
9-2422-26	SPRG.1.500X5.50-RED-HVY-DUTY	Rectangular	1 1/2(in) 40(mm)	5.50(in) 139(mm)	64.30(lbs per 1/10in) 113.0(N/mm)
9-2424-26	SPRG.1.500X6.00-RED-HVY-DUTY	Rectangular	1 1/2(in) 40(mm)	6.00(in) 152(mm)	59.00(lbs per 1/10in) 103.0(N/mm)
9-2428-26	SPRG.1.500X7.00-RED-HVY-DUTY	Rectangular	1 1/2(in) 40(mm)	7.00(in) 178(mm)	20.30(lbs per 1/10in) 88.0(N/mm)
9-2432-26	SPRG.1.500X8.00-RED-HVY-DUTY	Rectangular	1 1/2(in) 40(mm)	8.00(in) 203(mm)	43.80(lbs per 1/10in) 76.6(N/mm)
9-2440-26	SPRG.1.500x10.0-RED-HVY-DUTY	Rectangular	1 1/2(in) 40(mm)	10.00(in) 254(mm)	34.60(lbs per 1/10in) 60.6(N/mm)
9-2448-26	SPRG.1.500x12.0-RED-HVY-DUTY	Rectangular	1 1/2(in) 40(mm)	12.00(in) 305(mm)	28.70(lbs per 1/10in) 50.3(N/mm)
9-3210-26	SPRG.2.000X2.50-RED-HVY-DUTY	Rectangular	2(in) 50(mm)	2.50(in) 64(mm)	242.00(lbs per 1/10in) 423.0(N/mm)
9-3212-26	SPRG.2.000X3.00-RED-HVY-DUTY	Rectangular	2(in) 50(mm)	3.00(in) 76(mm)	193.00(lbs per 1/10in) 338.0(N/mm)
9-3214-26	SPRG.2.000X3.50-RED-HVY-DUTY	Rectangular	2(in) 50(mm)	3.50(in) 89(mm)	160.00(lbs per 1/10in) 281.0(N/mm)
9-3216-26	SPRG.2.000X4.00-RED-HVY-DUTY	Rectangular	2(in) 50(mm)	4.00(in) 102(mm)	140.00(lbs per 1/10in) 244.0(N/mm)
9-3218-26	SPRG.2.000X4.50-RED-HVY-DUTY	Rectangular	2(in) 50(mm)	4.50(in) 115(mm)	123.00(lbs per 1/10in) 215.0(N/mm)
9-3220-26	SPRG.2.000X5.00-RED-HVY-DUTY	Rectangular	2(in) 50(mm)	5.00(in) 127(mm)	108.00(lbs per 1/10in) 189.0(N/mm)
9-3222-26	SPRG.2.000X5.50-RED-HVY-DUTY	Rectangular	2(in) 50(mm)	5.50(in) 139(mm)	96.40(lbs per 1/10in) 169.0(N/mm)
9-3224-26	SPRG.2.000X6.00-RED-HVY-DUTY	Rectangular	2(in) 50(mm)	6.00(in) 152(mm)	88.00(lbs per 1/10in) 154.0(N/mm)
9-3228-26	SPRG.2.000X7.00-RED-HVY-DUTY	Rectangular	2(in) 50(mm)	7.00(in) 178(mm)	75.00(lbs per 1/10in) 131.0(N/mm)
9-3232-26	SPRG.2.000X8.00-RED-HVY-DUTY	Rectangular	2(in) 50(mm)	8.00(in) 203(mm)	65.30(lbs per 1/10in) 114.0(N/mm)
9-3240-26	SPRG.2.000x10.0-RED-HVY-DUTY	Rectangular	2(in) 50(mm)	10.00(in) 254(mm)	51.30(lbs per 1/10in) 89.7(N/mm)
9-3248-26	SPRG.2.000x12.0-RED-HVY-DUTY	Rectangular	2(in) 50(mm)	12.00(in) 305(mm)	42.60(lbs per 1/10in) 74.6(N/mm)

DieMax XL Springs: Extra Heavy Load (Yellow)

Part No.	Description	Wire Type	A - Hole Diameter	C - Free Length	Spring Constant
9-0604-36	SPRG.0.375X1.00-YELLOW-X-HEAVY	Rectangular	3/8(in) 10(mm)	1.00(in) 25(mm)	18.70(lbs per 1/10in) 32.8(N/mm)
9-0605-36	SPRG.0.375X1.25-YELLOW-X-HEAVY	Rectangular	3/8(in) 10(mm)	1.25(in) 32(mm)	14.60(lbs per 1/10in) 25.6(N/mm)
9-0606-36	SPRG.0.375X1.50-YELLOW-X-HEAVY	Rectangular	3/8(in) 10(mm)	1.50(in) 38(mm)	12.10(lbs per 1/10in) 21.2(N/mm)
9-0607-36	SPRG.0.375X1.75-YELLOW-X-HEAVY	Rectangular	3/8(in) 10(mm)	1.75(in) 44(mm)	10.10(lbs per 1/10in) 17.6(N/mm)
9-0608-36	SPRG.0.375X2.00-YELLOW-X-HEAVY	Rectangular	3/8(in) 10(mm)	2.00(in) 51(mm)	8.80(lbs per 1/10in) 15.3(N/mm)
9-0610-36	SPRG.0.375X2.50-YELLOW-X-HEAVY	Rectangular	3/8(in) 10(mm)	2.50(in) 64(mm)	7.00(lbs per 1/10in) 12.2(N/mm)
9-0612-36	SPRG.0.375X3.00-YELLOW-X-HEAVY	Rectangular	3/8(in) 10(mm)	3.00(in) 76(mm)	5.80(lbs per 1/10in) 10.1(N/mm)
9-0648-36	SPRG.0.375X12.0-YELLOW-X-HEAVY	Rectangular	3/8(in) 10(mm)	12.00(in) 305(mm)	1.40(lbs per 1/10in) 2.5(N/mm)
9-0804-36	SPRG.0.500X1.00-YELLOW-X-HEAVY	Rectangular	1/2(in) 12.5(mm)	1.00(in) 25(mm)	33.50(lbs per 1/10in) 58.6(N/mm)
9-0805-36	SPRG.0.500X1.25-YELLOW-X-HEAVY	Rectangular	1/2(in) 12.5(mm)	1.25(in) 32(mm)	25.20(lbs per 1/10in) 44.2(N/mm)
9-0806-36	SPRG.0.500X1.50-YELLOW-X-HEAVY	Rectangular	1/2(in) 12.5(mm)	1.50(in) 38(mm)	20.70(lbs per 1/10in) 36.2(N/mm)
9-0807-36	SPRG.0.500X1.75-YELLOW-X-HEAVY	Rectangular	1/2(in) 12.5(mm)	1.75(in) 44(mm)	17.50(lbs per 1/10in) 30.6(N/mm)
9-0808-36	SPRG.0.500X2.00-YELLOW-X-HEAVY	Rectangular	1/2(in) 12.5(mm)	2.00(in) 51(mm)	15.40(lbs per 1/10in) 27.0(N/mm)
9-0810-36	SPRG.0.500X2.50-YELLOW-X-HEAVY	Rectangular	1/2(in) 12.5(mm)	2.50(in) 64(mm)	12.50(lbs per 1/10in) 21.8(N/mm)
9-0812-36	SPRG.0.500X3.00-YELLOW-X-HEAVY	Rectangular	1/2(in) 12.5(mm)	3.00(in) 76(mm)	10.10(lbs per 1/10in) 17.7(N/mm)
9-0814-36	SPRG.0.500X3.50-YELLOW-X-HEAVY	Rectangular	1/2(in) 12.5(mm)	3.50(in) 89(mm)	8.50(lbs per 1/10in) 15.1(N/mm)
9-0848-36	SPRG.0.500x12.0-YELLOW-X-HEAVY	Rectangular	1/2(in) 12.5(mm)	12.00(in) 305(mm)	2.41(lbs per 1/10in) 4.2(N/mm)
9-1004-36	SPRG.0.625X1.00-YELLOW-X-HEAVY	Rectangular	5/8(in) 16(mm)	1.00(in) 25(mm)	72.70(lbs per 1/10in) 127.0(N/mm)
9-1005-36	SPRG.0.625X1.25-YELLOW-X-HEAVY	Rectangular	5/8(in) 16(mm)	1.25(in) 32(mm)	53.70(lbs per 1/10in) 94.1(N/mm)
9-1006-36	SPRG.0.625X1.50-YELLOW-X-HEAVY	Rectangular	5/8(in) 16(mm)	1.50(in) 38(mm)	43.30(lbs per 1/10in) 75.9(N/mm)
9-1007-36	SPRG.0.625X1.75-YELLOW-X-HEAVY	Rectangular	5/8(in) 16(mm)	1.75(in) 44(mm)	36.30(lbs per 1/10in) 63.6(N/mm)
9-1008-36	SPRG.0.625X2.00-YELLOW-X-HEAVY	Rectangular	5/8(in) 16(mm)	2.00(in) 51(mm)	31.70(lbs per 1/10in) 55.5(N/mm)
9-1010-36	SPRG.0.625X2.50-YELLOW-X-HEAVY	Rectangular	5/8(in) 16(mm)	2.50(in) 64(mm)	24.70(lbs per 1/10in) 43.3(N/mm)
9-1012-36	SPRG.0.625X3.00-YELLOW-X-HEAVY	Rectangular	5/8(in) 16(mm)	3.00(in) 76(mm)	20.30(lbs per 1/10in) 35.5(N/mm)
9-1014-36	SPRG.0.625X3.50-YELLOW-X-HEAVY	Rectangular	5/8(in) 16(mm)	3.50(in) 89(mm)	17.30(lbs per 1/10in) 30.3(N/mm)
9-1016-36	SPRG.0.625X4.00-YELLOW-X-HEAVY	Rectangular	5/8(in) 16(mm)	4.00(in) 102(mm)	15.10(lbs per 1/10in) 26.4(N/mm)
9-1048-36	SPRG.0.625X12.0-YELLOW-X-HEAVY	Rectangular	5/8(in) 16(mm)	12.00(in) 305(mm)	4.88(lbs per 1/10in) 8.6(N/mm)
9-1204-36	SPRG.0.750X1.00-YELLOW-X-HEAVY	Rectangular	3/4(in) 20(mm)	1.00(in) 25(mm)	183.00(lbs per 1/10in) 320.0(N/mm)
9-1205-36	SPRG.0.750X1.25-YELLOW-X-HEAVY	Rectangular	3/4(in) 20(mm)	1.25(in) 32(mm)	137.00(lbs per 1/10in) 240.0(N/mm)
9-1206-36	SPRG.0.750X1.50-YELLOW-X-HEAVY	Rectangular	3/4(in) 20(mm)	1.50(in) 38(mm)	111.00(lbs per 1/10in) 194.0(N/mm)
9-1207-36	SPRG.0.750X1.75-YELLOW-X-HEAVY	Rectangular	3/4(in) 20(mm)	1.75(in) 44(mm)	92.40(lbs per 1/10in) 162.0(N/mm)
9-1208-36	SPRG.0.750X2.00-YELLOW-X-HEAVY	Rectangular	3/4(in) 20(mm)	2.00(in) 51(mm)	79.70(lbs per 1/10in) 140.0(N/mm)
9-1210-36	SPRG.0.750X2.50-YELLOW-X-HEAVY	Rectangular	3/4(in) 20(mm)	2.50(in) 64(mm)	62.10(lbs per 1/10in) 109.0(N/mm)
9-1212-36	SPRG.0.750X3.00-YELLOW-X-HEAVY	Rectangular	3/4(in) 20(mm)	3.00(in) 76(mm)	51.20(lbs per 1/10in) 89.7(N/mm)
9-1214-36	SPRG.0.750X3.50-YELLOW-X-HEAVY	Rectangular	3/4(in) 20(mm)	3.50(in) 89(mm)	43.20(lbs per 1/10in) 75.6(N/mm)
9-1216-36	SPRG.0.750X4.00-YELLOW-X-HEAVY	Rectangular	3/4(in) 20(mm)	4.00(in) 102(mm)	37.30(lbs per 1/10in) 65.3(N/mm)
9-1218-36	SPRG.0.750X4.50-YELLOW-X-HEAVY	Rectangular	3/4(in) 20(mm)	4.50(in) 115(mm)	32.80(lbs per 1/10in) 57.5(N/mm)
9-1220-36	SPRG.0.750X5.00-YELLOW-X-HEAVY	Rectangular	3/4(in) 20(mm)	5.00(in) 127(mm)	29.50(lbs per 1/10in) 51.7(N/mm)
9-1222-36	SPRG.0.750X5.50-YELLOW-X-HEAVY	Rectangular	3/4(in) 20(mm)	5.50(in) 139(mm)	26.60(lbs per 1/10in) 46.6(N/mm)
9-1224-36	SPRG.0.750X6.00-YELLOW-X-HEAVY	Rectangular	3/4(in) 20(mm)	6.00(in) 152(mm)	24.30(lbs per 1/10in) 42.5(N/mm)
9-1248-36	SPRG.0.750x12.0-YELLOW-X-HEAVY	Rectangular	3/4(in) 20(mm)	12.00(in) 305(mm)	12.00(lbs per 1/10in) 20.9(N/mm)
9-1605-36	SPRG.1.000X1.25-YELLOW-X-HEAVY	Rectangular	1(in) 25(mm)	1.25(in) 32(mm)	202.00(lbs per 1/10in) 354.0(N/mm)
9-1606-36	SPRG.1.000X1.50-YELLOW-X-HEAVY	Rectangular	1(in) 25(mm)	1.50(in) 38(mm)	160.00(lbs per 1/10in) 280.0(N/mm)
9-1607-36	SPRG.1.000X1.75-YELLOW-X-HEAVY	Rectangular	1(in) 25(mm)	1.75(in) 44(mm)	132.00(lbs per 1/10in) 232.0(N/mm)
9-1608-36	SPRG.1.000X2.00-YELLOW-X-HEAVY	Rectangular	1(in) 25(mm)	2.00(in) 51(mm)	113.00(lbs per 1/10in) 198.0(N/mm)
9-1610-36	SPRG.1.000X2.50-YELLOW-X-HEAVY	Rectangular	1(in) 25(mm)	2.50(in) 64(mm)	87.80(lbs per 1/10in) 154.0(N/mm)
9-1612-36	SPRG.1.000X3.00-YELLOW-X-HEAVY	Rectangular	1(in) 25(mm)	3.00(in) 76(mm)	71.40(lbs per 1/10in) 125.0(N/mm)
9-1614-36	SPRG.1.000X3.50-YELLOW-X-HEAVY	Rectangular	1(in) 25(mm)	3.50(in) 89(mm)	60.20(lbs per 1/10in) 105.0(N/mm)
9-1616-36	SPRG.1.000X4.00-YELLOW-X-HEAVY	Rectangular	1(in) 25(mm)	4.00(in) 102(mm)	52.00(lbs per 1/10in) 91.1(N/mm)
9-1618-36	SPRG.1.000X4.50-YELLOW-X-HEAVY	Rectangular	1(in) 25(mm)	4.50(in) 115(mm)	46.20(lbs per 1/10in) 80.9(N/mm)
Part No.	Description	Wire Type	A - Hole Diameter	C - Free Length	Spring Constant
9-1620-36	SPRG.1.000X5.00-YELLOW-X-HEAVY	Rectangular	1(in) 25(mm)	5.00(in) 127(mm)	41.20(lbs per 1/10in) 72.2(N/mm)
9-1622-36	SPRG.1.000X5.50-YELLOW-X-HEAVY	Rectangular	1(in) 25(mm)	5.50(in) 140(mm)	37.50(lbs per 1/10in) 65.6(N/mm)
9-1624-36	SPRG.1.000X6.00-YELLOW-X-HEAVY	Rectangular	1(in) 25(mm)	6.00(in) 152(mm)	34.40(lbs per 1/10in) 60.2(N/mm)
9-1628-36	SPRG.1.000X7.00-YELLOW-X-HEAVY	Rectangular	1(in) 25(mm)	7.00(in) 178(mm)	29.30(lbs per 1/10in) 51.3(N/mm)
9-1632-36	SPRG.1.000X8.00-YELLOW-X-HEAVY	Rectangular	1(in) 25(mm)	8.00(in) 203(mm)	25.50(lbs per 1/10in) 44.7(N/mm)
9-1648-36	SPRG.1.000x12.0-YELLOW-X-HEAVY	Rectangular	1(in) 25(mm)	12.00(in) 305(mm)	16.90(lbs per 1/10in) 29.5(N/mm)
9-2006-36	SPRG.1.250X1.50-YELLOW-X-HEAVY	Rectangular	1 1/4(in) 32(mm)	1.50(in) 38(mm)	279.00(lbs per 1/10in) 488.0(N/mm)
9-2007-36	SPRG.1.250X1.75-YELLOW-X-HEAVY	Rectangular	1 1/4(in) 32(mm)	1.75(in) 44(mm)	231.00(lbs per 1/10in) 404.0(N/mm)
9-2008-36	SPRG.1.250X2.00-YELLOW-X-HEAVY	Rectangular	1 1/4(in) 32(mm)	2.00(in) 51(mm)	197.00(lbs per 1/10in) 344.0(N/mm)
9-2010-36	SPRG.1.250X2.50-YELLOW-X-HEAVY	Rectangular	1 1/4(in) 32(mm)	2.50(in) 64(mm)	152.00(lbs per 1/10in) 266.0(N/mm)
9-2012-36	SPRG.1.250X3.00-YELLOW-X-HEAVY	Rectangular	1 1/4(in) 32(mm)	3.00(in) 76(mm)	123.00(lbs per 1/10in) 215.0(N/mm)
9-2014-36	SPRG.1.250X3.50-YELLOW-X-HEAVY	Rectangular	1 1/4(in) 32(mm)	3.50(in) 89(mm)	104.00(lbs per 1/10in) 182.0(N/mm)
9-2016-36	SPRG.1.250X4.00-YELLOW-X-HEAVY	Rectangular	1 1/4(in) 32(mm)	4.00(in) 102(mm)	88.90(lbs per 1/10in) 156.0(N/mm)
9-2018-36	SPRG.1.250X4.50-YELLOW-X-HEAVY	Rectangular	1 1/4(in) 32(mm)	4.50(in) 115(mm)	77.50(lbs per 1/10in) 136.0(N/mm)
9-2020-36	SPRG.1.250X5.00-YELLOW-X-HEAVY	Rectangular	1 1/4(in) 32(mm)	5.00(in) 127(mm)	69.60(lbs per 1/10in) 122.0(N/mm)
9-2022-36	SPRG.1.250X5.50-YELLOW-X-HEAVY	Rectangular	1 1/4(in) 32(mm)	5.50(in) 140(mm)	63.60(lbs per 1/10in) 111.0(N/mm)
9-2024-36	SPRG.1.250X6.00-YELLOW-X-HEAVY	Rectangular	1 1/4(in) 32(mm)	6.00(in) 152(mm)	57.60(lbs per 1/10in) 101.0(N/mm)
9-2028-36	SPRG.1.250X7.00-YELLOW-X-HEAVY	Rectangular	1 1/4(in) 32(mm)	7.00(in) 178(mm)	48.90(lbs per 1/10in) 85.5(N/mm)
9-2032-36	SPRG.1.250X8.00-YELLOW-X-HEAVY	Rectangular	1 1/4(in) 32(mm)	8.00(in) 203(mm)	42.60(lbs per 1/10in) 74.7(N/mm)
9-2040-36	SPRG.1.250x10.0-YELLOW-X-HEAVY	Rectangular	1 1/4(in) 32(mm)	10.00(in) 254(mm)	34.00(lbs per 1/10in) 59.5(N/mm)
9-2048-36	SPRG.1.250x12.0-YELLOW-X-HEAVY	Rectangular	1 1/4(in) 32(mm)	12.00(in) 305(mm)	28.30(lbs per 1/10in) 49.5(N/mm)
9-2408-36	SPRG.1.500X2.00-YELLOW-X-HEAVY	Rectangular	1 1/2(in) 40(mm)	2.00(in) 51(mm)	319.00(lbs per 1/10in) 559.0(N/mm)
9-2410-36	SPRG.1.500X2.50-YELLOW-X-HEAVY	Rectangular	1 1/2(in) 40(mm)	2.50(in) 64(mm)	241.00(lbs per 1/10in) 421.0(N/mm)
9-2412-36	SPRG.1.500X3.00-YELLOW-X-HEAVY	Rectangular	1 1/2(in) 40(mm)	3.00(in) 76(mm)	193.00(lbs per 1/10in) 338.0(N/mm)
9-2414-36	SPRG.1.500X3.50-YELLOW-X-HEAVY	Rectangular	1 1/2(in) 40(mm)	3.50(in) 89(mm)	160.00(lbs per 1/10in) 279.0(N/mm)
9-2416-36	SPRG.1.500X4.00-YELLOW-X-HEAVY	Rectangular	1 1/2(in) 40(mm)	4.00(in) 102(mm)	139.00(lbs per 1/10in) 244.0(N/mm)
9-2418-36	SPRG.1.500X4.50-YELLOW-X-HEAVY	Rectangular	1 1/2(in) 40(mm)	4.50(in) 115(mm)	122.00(lbs per 1/10in) 214.0(N/mm)
9-2420-36	SPRG.1.500X5.00-YELLOW-X-HEAVY	Rectangular	1 1/2(in) 40(mm)	5.00(in) 127(mm)	108.00(lbs per 1/10in) 190.0(N/mm)
9-2422-36	SPRG.1.500X5.50-YELLOW-X-HEAVY	Rectangular	1 1/2(in) 40(mm)	5.50(in) 140(mm)	97.60(lbs per 1/10in) 171.0(N/mm)
9-2424-36	SPRG.1.500X6.00-YELLOW-X-HEAVY	Rectangular	1 1/2(in) 40(mm)	6.00(in) 152(mm)	88.70(lbs per 1/10in) 155.0(N/mm)
9-2428-36	SPRG.1.500X7.00-YELLOW-X-HEAVY	Rectangular	1 1/2(in) 40(mm)	7.00(in) 178(mm)	75.00(lbs per 1/10in) 131.0(N/mm)
9-2432-36	SPRG.1.500X8.00-YELLOW-X-HEAVY	Rectangular	1 1/2(in) 40(mm)	8.00(in) 203(mm)	65.00(lbs per 1/10in) 144.0(N/mm)
9-2440-36	SPRG.1.500x10.0-YELLOW-X-HEAVY	Rectangular	1 1/2(in) 40(mm)	10.00(in) 254(mm)	51.60(lbs per 1/10in) 90.4(N/mm)
9-2448-36	SPRG.1.500x12.0-YELLOW-X-HEAVY	Rectangular	1 1/2(in) 40(mm)	12.00(in) 305(mm)	42.80(lbs per 1/10in) 75.0(N/mm)
9-3210-36	SPRG.2.000X2.50-YELLOW-X-HEAVY	Rectangular	2(in) 50(mm)	2.50(in) 64(mm)	414.00(lbs per 1/10in) 724.0(N/mm)
9-3212-36	SPRG.2.000X3.00-YELLOW-X-HEAVY	Rectangular	2(in) 50(mm)	3.00(in) 76(mm)	327.00(lbs per 1/10in) 573.0(N/mm)
9-3214-36	SPRG.2.000X3.50-YELLOW-X-HEAVY	Rectangular	2(in) 50(mm)	3.50(in) 89(mm)	271.00(lbs per 1/10in) 474.0(N/mm)
9-3216-36	SPRG.2.000X4.00-YELLOW-X-HEAVY	Rectangular	2(in) 50(mm)	4.00(in) 102(mm)	231.00(lbs per 1/10in) 404.0(N/mm)
9-3218-36	SPRG.2.000X4.50-YELLOW-X-HEAVY	Rectangular	2(in) 50(mm)	4.50(in) 115(mm)	201.00(lbs per 1/10in) 353.0(N/mm)
9-3220-36	SPRG.2.000X5.00-YELLOW-X-HEAVY	Rectangular	2(in) 50(mm)	5.00(in) 127(mm)	179.00(lbs per 1/10in) 313.0(N/mm)
9-3222-36	SPRG.2.000X5.50-YELLOW-X-HEAVY	Rectangular	2(in) 50(mm)	5.50(in) 140(mm)	161.00(lbs per 1/10in) 282.0(N/mm)
9-3224-36	SPRG.2.000X6.00-YELLOW-X-HEAVY	Rectangular	2(in) 50(mm)	6.00(in) 152(mm)	145.00(lbs per 1/10in) 255.0(N/mm)
9-3228-36	SPRG.2.000X7.00-YELLOW-X-HEAVY	Rectangular	2(in) 50(mm)	7.00(in) 178(mm)	123.00(lbs per 1/10in) 215.0(N/mm)
9-3232-36	SPRG.2.000X8.00-YELLOW-X-HEAVY	Rectangular	2(in) 50(mm)	8.00(in) 203(mm)	106.00(lbs per 1/10in) 186.0(N/mm)
9-3240-36	SPRG.2.000x10.0-YELLOW-X-HEAVY	Rectangular	2(in) 50(mm)	10.00(in) 254(mm)	83.50(lbs per 1/10in) 146.0(N/mm)
9-3248-36	SPRG.2.000x12.0-YELLOW-X-HEAVY	Rectangular	2(in) 50(mm)	12.00(in) 305(mm)	68.90(lbs per 1/10in) 121.0(N/mm)

专业进口德国Danly弹簧

专业进口德国Danly弹簧

专业进口德国Danly弹簧

为您推荐
